Mercedes M-Class wheel fitment — 166
Overview
The Mercedes-Benz M-Class (W166) is a mid-size luxury SUV produced by Mercedes-Benz from 2011 to 2015. It was the third generation of the M-Class, which was renamed GLE in 2015 with minor styling changes and platform updates. The W166 model moved away from the body-on-frame construction used in previous generations to a unibody design, aligning it more closely with Mercedes-Benz's sedan lineup. This transition aimed at improving ride quality and handling while maintaining its off-road capabilities. Production initially took place in Stuttgart for European and Australian markets before moving entirely to Vance, Alabama, USA, in 2015.
History & notable variants
The W166 generation of the M-Class was introduced in 2011 as a significant update over the previous model (W164). It featured a new unibody platform for improved ride quality and handling. Notable changes included revised styling, enhanced interior technology, and an expanded range of engine options to meet growing market demands. The W166 was built in Stuttgart until 2015 when production shifted entirely to the Vance plant in Alabama with minor updates.
Mercedes M-Class wheel fitment
Everything below is what the fit-check uses for Mercedes M-Class wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Mercedes M-Class 166.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | radius |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9J–11J | ET37–ET56 |
| Rear (staggered) | 9.5J–11J | ET45–ET50 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| ML 300 4MATIC | V6-Ottomotor, 3,498 cc, Motorkenndaten | petrol | 185 kW (252 PS) | 4MATIC, 2012 to 2015 |
| ML 350 4MATIC | V6-Ottomotor, 3,498 cc, Motorkenndaten | petrol | 225 kW (306 PS) | 4MATIC, 2011 to 2014 |
| ML 400 4MATIC | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 245 kW (333 PS) | 4MATIC, 2015 |
| ML 500 4MATIC | V8-Ottomotor, 4,663 cc, Motorkenndaten | petrol | 300 kW (408 PS) | 4MATIC, 2012 to 2015 |
| ML 63 AMG | V8-Ottomotor, 5,461 cc, Motorkenndaten | petrol | 386 kW (525 PS) | AWD, 2012 to 2015 |
| ML 250 BlueTEC 4MATIC | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 150 kW (204 PS) | 4MATIC, 2011 to 2015 |
| ML 350 BlueTEC 4MATIC | V6-Dieselmotor, 2,987 cc, Motorkenndaten | diesel | 190 kW (258 PS) | 4MATIC, 2011 to 2015 |
| GLE 320 4MATIC | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 200 kW (272 PS) | 4MATIC, 2015 to 2018 |
| GLE 350 | V6-Ottomotor, 3,498 cc, Motorkenndaten | petrol | 225 kW (306 PS) | RWD, 2015 to 2018 |
| GLE 350 4MATIC | V6-Ottomotor, 3,498 cc, Motorkenndaten | petrol | 225 kW (306 PS) | 4MATIC, 2015 to 2018 |
| GLE 400 4MATIC | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 245 kW (333 PS) | 4MATIC, 2015 to 2018 |
| GLE 43 AMG 4MATIC | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 270 kW (367 PS) | 4MATIC, 2015 to 2017 |
| GLE 43 AMG 4MATIC | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 287 kW (390 PS) | 4MATIC, 2017 to 2018 |
| GLE 500 4MATIC | V8-Ottomotor, 4,663 cc, Motorkenndaten | petrol | 320 kW (435 PS) | 4MATIC, 2015 |
| GLE 500 4MATIC | V8-Ottomotor, 4,663 cc, Motorkenndaten | petrol | 335 kW (455 PS) | 4MATIC, 2015 to 2018 |
| GLE 500 e | V6-Ottomotor + Elektromotor, 2,996 cc, Motorkenndaten | petrol | 245 kW (333 PS) | AWD, 2015 to 2018 |
| AMG GLE 63 | V8-Ottomotor, 5,461 cc, Motorkenndaten | petrol | 410 kW (557 PS) | AWD, 2015 to 2018 |
| AMG GLE 63 S | V8-Ottomotor, 5,461 cc, Motorkenndaten | petrol | 430 kW (585 PS) | AWD, 2015 to 2018 |
| GLE 250 d | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 150 kW (204 PS) | RWD, 2015 to 2018 |
| GLE 250 d 4MATIC | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 150 kW (204 PS) | 4MATIC, 2015 to 2018 |
| GLE 350 d 4MATIC | V6-Dieselmotor, 2,987 cc, Motorkenndaten | diesel | 190 kW (258 PS) | 4MATIC, 2015 to 2018 |
Source: Mercedes-Benz W 166, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| ML 300 4MATIC | 185 kW (252 PS) | 8.5 s | 235 km/h (146 mph) |
| ML 350 4MATIC | 225 kW (306 PS) | 7.6 s | 240 km/h (149 mph) |
| ML 400 4MATIC | 245 kW (333 PS) | 6.1 s | 247 km/h (153 mph) |
| ML 500 4MATIC | 300 kW (408 PS) | 5.6 s | 250 km/h (155 mph) |
| ML 63 AMG | 386 kW (525 PS) | 4.7 to 4.8 s | 250 to 280 km/h (155 to 174 mph) |
| ML 250 BlueTEC 4MATIC | 150 kW (204 PS) | 9 s | 210 km/h (130 mph) |
| ML 350 BlueTEC 4MATIC | 190 kW (258 PS) | 7.4 s | 224 km/h (139 mph) |
| GLE 320 4MATIC | 200 kW (272 PS) | 7.6 s | 230 km/h (143 mph) |
| GLE 350 | 225 kW (306 PS) | 7.5 s | 240 km/h (149 mph) |
| GLE 350 4MATIC | 225 kW (306 PS) | 7.5 s | 240 km/h (149 mph) |
| GLE 400 4MATIC | 245 kW (333 PS) | 6.1 s | 247 km/h (153 mph) |
| GLE 43 AMG 4MATIC | 270 kW (367 PS) | 5.7 s | 250 km/h (155 mph) |
| GLE 43 AMG 4MATIC | 287 kW (390 PS) | 5.7 s | 250 km/h (155 mph) |
| GLE 500 4MATIC | 320 kW (435 PS) | 5.3 s | 250 km/h (155 mph) |
| GLE 500 4MATIC | 335 kW (455 PS) | 5.1 s | 250 km/h (155 mph) |
| GLE 500 e | 245 kW (333 PS) | 5.3 s | 245 km/h (152 mph) |
| AMG GLE 63 | 410 kW (557 PS) | 4.3 s | 250 to 280 km/h (155 to 174 mph) |
| AMG GLE 63 S | 430 kW (585 PS) | 4.2 s | 250 to 280 km/h (155 to 174 mph) |
| GLE 250 d | 150 kW (204 PS) | 8.6 s | 210 km/h (130 mph) |
| GLE 250 d 4MATIC | 150 kW (204 PS) | 8.6 s | 210 km/h (130 mph) |
| GLE 350 d 4MATIC | 190 kW (258 PS) | 7.1 s | 225 km/h (140 mph) |
Source: Mercedes-Benz W 166, de.wikipedia.org.
Dimensions
| Length | 4,804 to 4,852 mm |
| Width | 1,926 to 1,971 mm |
| Height | 1,760 to 1,796 mm |
| Wheelbase | 2,915 mm |
| Kerb weight | 2,130 to 2,345 kg |
Source: Mercedes-Benz W 166, de.wikipedia.org.
Body styles & production
| Body styles | Kombi |
| Produced | 2012–2015 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Improved ride quality and handling; advanced technology features; enhanced off-road capabilities
- Cons: Higher price point compared to previous generation; some models may have compromised interior space due to unibody design
- Common issues: None reported
