Mercedes R Class 251 side profile — Mercedes R Class wheel fitment

Mercedes R Class wheel fitment — 251

By Torque, AIWheelTech vehicle & fitment specialist · 2004–2023
Mercedes R Class wheel fitment in one line: The Mercedes R Class 251 (2004–2023) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts. It accepts ~8.5J–10J wheels at ET27–ET43 front; staggered setups run 9.5J–11J rear (ET28–ET45).

Overview

The Mercedes-Benz R-Class is a mid-size luxury MPV introduced by Mercedes-Benz in 2005 for the 2006 model year, following the success of smaller A- and B-Class MPVs. It was manufactured in Vance, Alabama until 2015 when production shifted to Mishawaka, Indiana due to reduced volume needs. The R-Class shares its platform with the M-Class (W164) and GL-Class (X164), available in standard and long wheelbase versions. Initially marketed as a 'Sports Cruiser' and later as a 'Family Tourer', it was discontinued globally by 2013 except for China where production continued until 2017.

Mercedes R Class wheel fitment

Start with the hub. The Mercedes R Class 251 spec table gives the bolt pattern and bore; the second table is the aftermarket window for Mercedes R Class wheel fitment.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Seat typetapered
Factory setupstaggered
TPMSnone
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8.5J–10JET27–ET43
Rear (staggered)9.5J–11JET28–ET45

As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes R Class →Get them fitted (UK)

UK popularity & demand

~1,436 Mercedes R Class licensed on UK roads — top 27% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 1,436 Mercedes R Class on UK roads, placing it in the top 27% of car models by volume across our fitment database.

With that many on the road, Mercedes R Class wheel fitment is a spec fitters see constantly. We keep it current for that reason.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive, years
R 280 (Lang)2,996 ccpetrol170 kW (231 PS)2007 to 2009
R 300 (Lang)2,996 ccpetrol170 kW (231 PS)2009 to 2014
R 320 4MATIC Lang / (China)2,996 ccpetrol200 kW (272 PS)4MATIC, 2014 to 2017
R 350 (Lang)3,498 ccpetrol200 kW (272 PS)2007 to 2010
R 350 4MATIC (Lang)3,498 ccpetrol200 kW (272 PS)4MATIC, 2006 to 2013
R 350 4MATIC BlueEFFICIENCY (Lang)3,498 ccpetrol225 kW (306 PS)4MATIC, 2012 to 2014
R 400 4MATIC Lang / (China)2,996 ccpetrol245 kW (333 PS)4MATIC, 2014 to 2017
R 500 4MATIC (Lang)4,966 ccpetrol225 kW (306 PS)4MATIC, 2006 to 2007
R 500 4MATIC (Lang)5,461 ccpetrol285 kW (388 PS)4MATIC, 2007 to 2014
R 63 AMG 4MATIC (Lang)6,208 ccpetrol375 kW (510 PS)4MATIC, 2006 to 2007
R 280 CDI 4MATIC Kurz2,987 ccdiesel140 kW (190 PS)4MATIC, 2007 to 2009
R 280 CDI (Lang)2,987 ccdiesel140 kW (190 PS)2007 to 2009
R 300 CDI 4MATIC Kurz2,987 ccdiesel140 kW (190 PS)4MATIC, 2009 to 2010
R 300 CDI BlueEFFICIENCY (Lang)2,987 ccdiesel140 kW (190 PS)2009 to 2012
R 350 BlueTEC 4MATIC Lang2,987 ccdiesel155 kW (211 PS)4MATIC, 2009 to 2012
R 320 CDI (Lang)2,987 ccdiesel165 kW (224 PS)2007 to 2009
R 320 CDI 4MATIC (Lang)2,987 ccdiesel165 kW (224 PS)4MATIC, 2006 to 2009
R 350 CDI 4MATIC (Lang)2,987 ccdiesel165 kW (224 PS)4MATIC, 2009 to 2010
R 350 CDI 4MATIC (Lang)2,987 ccdiesel195 kW (265 PS)4MATIC, 2010 to 2012

Source: Mercedes-Benz Baureihe 251, de.wikipedia.org.

Dimensions

Length4,922 to 5,157 mm
Width1,922 mm
Height1,661 to 1,663 mm
Wheelbase2,980 to 3,215 mm
Kerb weight2,175 to 2,405 kg

Source: Mercedes-Benz Baureihe 251, de.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body stylesKombi
Produced2004–2023

Trim levels

R 320 CDIR 400R 350 BlueTEC

Factory colours

Obsidian Black MetallicBlack, Deep Black, TiefschwarzPolar WhiteAprikosengelbCapri Blue MetallicJeansblau MetallicDesert Silver MetallicCubanitsilber Metallic, Pewter MetallicBrillantsilber MetallicTectite Gray MetallicSteel Gray Metallic, Tenoritgrau MetallicAlabaster WhiteAlaska WhiteBlackIridium Silver MetallicCalcite White

History & notable variants

In May 2007, Mercedes-Benz expanded the R-Class model range with more engine options and rear-wheel-drive availability. A major update in 2010 included a facelift and introduction of new V8 engines. The AMG version, R 63 AMG 4MATIC, was introduced at the 2006 North American International Auto Show but had limited sales due to poor handling dynamics and was discontinued after one model year.
