By Torque, AIWheelTech vehicle & fitment specialist · 2007–2013
Mercedes S-Class AMG wheel fitment at a glance — The Mercedes S 63/65 W221 (2007–2013) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts. It accepts ~8.5J–10J wheels at ET25–ET40 front; staggered setups run 9.5J–11J rear (ET25–ET40).
Overview
The Mercedes-Benz S-Class is a series of full-sized luxury sedans and coupés produced by Mercedes-Benz. The 221 generation, also known as the W221, was part of this lineage but specific production years for this exact model are not explicitly stated in the provided reference.
Mercedes S-Class AMG wheel fitment
Mercedes S-Class AMG wheel fitment for the Mercedes S 63/65 W221 (2007–2013): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
Bolt pattern (PCD)
5x112
Centre bore
66.6 mm
Bolt / thread
M14x1.5 (bolts)
Seat type
radius
Factory setup
staggered
TPMS
direct
Run-flat
Yes
Aftermarket wheel sizes — read per position:
Position
Width
Offset
Front
8.5J–10J
ET25–ET40
Rear (staggered)
9.5J–11J
ET25–ET40
As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Obsidian Black MetallicBlack Diamond MetallicCashmere MetallicMystic White PearlDesigno Mauritiusblau MetallicChablis MetallicAlmadinschwarz MetallicBlack Opal MetallicBrilliant Emerald MetallicJade Green MetallicMystic Blue PearlDesigno Mocha Black MetallicVaricolor III MetallicChalcedonblau PearlCapri Blue MetallicFlint Gray MetallicDesigno Mystic Red MetallicAndorite Gray MetallicDeep Black, Tiefschwarz, BlackDesigno Graphite Green Metallic
History & notable variants
Introduced in 1972 with the W116 series, the S-Class has been Mercedes-Benz's flagship luxury sedan. The W221 generation is a continuation of this legacy, though detailed history and notable developments specific to the W221 are not fully outlined in the given reference.
