Mercedes S-Class wheel fitment — 222, 221
Before you buy wheels, the Mercedes S-Class wheel fitment facts: The Mercedes S-Class 222, 221 (2013–2017) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~8J–9.5J wheels at ET15–ET38 front; staggered setups run 9.5J–11J rear (ET26–ET48).
Mercedes S-Class wheel fitment
Mercedes S-Class wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Mercedes S-Class 222, 221 (2013–2017).
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8J–9.5J | ET15–ET38 |
| Rear (staggered) | 9.5J–11J | ET26–ET48 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Overview
The Mercedes-Benz S-Class is a series of full-sized luxury sedans and coupés produced by Mercedes-Benz. The generation referred to as 222 and 221 does not have specific production years mentioned for this exact model range in the provided REFERENCE, but it follows the lineage from earlier generations starting with W116 (introduced in 1972). This generation is part of a long line of luxury vehicles that debuted many innovations including drivetrain technologies and safety systems. The S-Class is positioned as Mercedes-Benz's flagship model above other models.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| S 400 HYBRID (L) / S 400 h (L) | V6-Ottomotor + Elektromotor, 3,498 cc, Motorkenndaten | petrol | 225 kW (306 PS) | RWD, 2013 to 2017 |
| S 400 4MATIC (L) | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 245 kW (333 PS) | 4MATIC, 2015 to 2017 |
| S 450 (L) | R6-Ottomotor + Elektromotor, 2,999 cc, Motorkenndaten | petrol | 270 kW (367 PS) | RWD, 2017 to present |
| S 450 4MATIC (L) | R6-Ottomotor + Elektromotor, 2,999 cc, Motorkenndaten | petrol | 270 kW (367 PS) | 4MATIC, 2017 to present |
| S 500 (L) | R6-Ottomotor + Elektromotor, 2,999 cc, Motorkenndaten | petrol | 320 kW (435 PS) | RWD, 2017 to present |
| S 550 HYBRID PLUS L / S 550 e L | V6-Ottomotor + Elektromotor, 2,996 cc, Motorkenndaten | petrol | 245 kW (333 PS) | RWD, 2014 to 2017 |
| S 500 (L) | V8-Ottomotor, 4,663 cc, Motorkenndaten | petrol | 335 kW (455 PS) | RWD, 2013 to 2017 |
| S 500 4MATIC (L) | V8-Ottomotor, 4,663 cc, Motorkenndaten | petrol | 335 kW (455 PS) | 4MATIC, 2013 to 2017 |
| S 560 (L) | V8-Ottomotor, 3,982 cc, Motorkenndaten | petrol | 345 kW (469 PS) | RWD, 2017 to present |
| S 560 4MATIC (L) | V8-Ottomotor, 3,982 cc, Motorkenndaten | petrol | 345 kW (469 PS) | 4MATIC, 2017 to present |
| S 560 e L | V6-Ottomotor + Elektromotor, 2,996 cc, Motorkenndaten | petrol | 270 kW (367 PS) | RWD, 2018 to present |
| S 63 AMG (L) | V8-Ottomotor, 5,461 cc, Motorkenndaten | petrol | 430 kW (585 PS) | RWD, 2013 to 2017 |
| S 63 AMG 4MATIC L | V8-Ottomotor, 5,461 cc, Motorkenndaten | petrol | 430 kW (585 PS) | 4MATIC, 2013 to 2017 |
| AMG S 63 4MATIC+ L | V8-Ottomotor, 3,982 cc, Motorkenndaten | petrol | 450 kW (612 PS) | 4MATIC+, 2017 to present |
| S 600 L | V12-Ottomotor, 5,980 cc, Motorkenndaten | petrol | 390 kW (530 PS) | RWD, 2014 to present |
| AMG S 65 L | V12-Ottomotor, 5,980 cc, Motorkenndaten | petrol | 463 kW (630 PS) | RWD, 2014 to 2019 |
| Maybach S 400 4MATIC | V6-Ottomotor, 2,996 cc | petrol | 245 kW (333 PS) | 4MATIC, 2015 to 2017 |
| Maybach S 500 | V8-Ottomotor, 4,663 cc | petrol | 335 kW (455 PS) | RWD, 2015 to 2017 |
| Maybach S 500 4MATIC | V8-Ottomotor, 4,663 cc | petrol | 335 kW (455 PS) | 4MATIC, 2015 to 2017 |
| Maybach S 560 | V8-Ottomotor, 3,982 cc | petrol | 345 kW (469 PS) | RWD, 2017 to present |
| Maybach S 560 4MATIC | V8-Ottomotor, 3,982 cc | petrol | 345 kW (469 PS) | 4MATIC, 2017 to present |
| Maybach S 600 | V12-Ottomotor, 5,980 cc | petrol | 390 kW (530 PS) | RWD, 2015 to 2017 |
| Maybach S 650 / (S 680 für chinesischen Markt) | V12-Ottomotor, 5,980 cc | petrol | 463 kW (630 PS) | RWD, 2017 to 2020 |
| Maybach S 600 Pullman | V12-Ottomotor, 5,980 cc | petrol | 390 kW (530 PS) | RWD, 2015 to 2018 |
| Maybach S 650 Pullman | V12-Ottomotor | petrol | 463 kW (630 PS) | RWD, 2018 to 2020 |
| S 350 L / S 320 L | V6-Ottomotor, 2,996 cc, Motorkenndaten | petrol | 200 kW (272 PS) | RWD |
| S 400 L | V6-Ottomotor, 3,498 cc, Motorkenndaten | petrol | 245 kW (333 PS) | RWD |
| S 400 L 4MATIC | V6-Ottomotor, 3,498 cc, Motorkenndaten | petrol | 245 kW (333 PS) | 4MATIC |
| S 500 e L | V6-Ottomotor, + Elektromotor, 2,996 cc, Motorkenndaten | petrol | 325 kW (442 PS) | RWD |
| S 500 L 4MATIC | V8-Ottomotor, Motorkenndaten | petrol | 310 kW (422 PS) | 4MATIC, 2015 to 2020 |
| S 300 BlueTEC HYBRID (L) / S 300 h (L) | R4-Dieselmotor + Elektromotor, 2,143 cc, Motorkenndaten | diesel | 150 kW (204 PS) | RWD, 2014 to 2017 |
| S 350 BlueTEC (L) / S 350 d (L) / S 350 CDI L | V6-Dieselmotor, 2,987 cc, Motorkenndaten | diesel | 190 kW (258 PS) | RWD, 2013 to 2017 |
| S 350 BlueTEC 4MATIC (L) / S 350 d 4 MATIC | V6-Dieselmotor, 2,987 cc, Motorkenndaten | diesel | 190 kW (258 PS) | 4MATIC, 2014 to 2017 |
| S 350 d (L) | R6-Dieselmotor, 2,925 cc, Motorkenndaten | diesel | 210 kW (286 PS) | RWD, 2017 to 2020 |
| S 350 d 4MATIC (L) | R6-Dieselmotor, 2,925 cc, Motorkenndaten | diesel | 210 kW (286 PS) | 4MATIC, 2017 to 2020 |
| S 400 d (L) | R6-Dieselmotor, 2,925 cc, Motorkenndaten | diesel | 250 kW (340 PS) | RWD, 2017 to 2020 |
| S 400 d 4MATIC (L) | R6-Dieselmotor, 2,925 cc, Motorkenndaten | diesel | 250 kW (340 PS) | 4MATIC, 2017 to 2020 |
Source: Mercedes-Benz Baureihe 222, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| S 400 HYBRID (L) / S 400 h (L) | 225 kW (306 PS) | 6.8 s | 250 km/h (155 mph) |
| S 400 4MATIC (L) | 245 kW (333 PS) | 6.1 s | 250 km/h (155 mph) |
| S 450 (L) | 270 kW (367 PS) | 5.1 s | 250 km/h (155 mph) |
| S 450 4MATIC (L) | 270 kW (367 PS) | 4.9 s | 250 km/h (155 mph) |
| S 500 (L) | 320 kW (435 PS) | 4.8 s | 250 km/h (155 mph) |
| S 550 HYBRID PLUS L / S 550 e L | 245 kW (333 PS) | 5.2 s | 250 km/h (155 mph) |
| S 500 (L) | 335 kW (455 PS) | 4.8 s | 250 km/h (155 mph) |
| S 500 4MATIC (L) | 335 kW (455 PS) | 4.8 s | 250 km/h (155 mph) |
| S 560 (L) | 345 kW (469 PS) | 4.7 s | 250 km/h (155 mph) |
| S 560 4MATIC (L) | 345 kW (469 PS) | 4.6 s | 250 km/h (155 mph) |
| S 560 e L | 270 kW (367 PS) | 5 s | 250 km/h (155 mph) |
| S 63 AMG (L) | 430 kW (585 PS) | 4.4 s | 250 to 300 km/h (155 to 186 mph) |
| S 63 AMG 4MATIC L | 430 kW (585 PS) | 4 s | 250 to 300 km/h (155 to 186 mph) |
| AMG S 63 4MATIC+ L | 450 kW (612 PS) | 3.5 to 3.6 s | 250 to 300 km/h (155 to 186 mph) |
| S 600 L | 390 kW (530 PS) | 4.6 s | 250 km/h (155 mph) |
| AMG S 65 L | 463 kW (630 PS) | 4.2 to 4.3 s | 250 to 300 km/h (155 to 186 mph) |
| Maybach S 400 4MATIC | 245 kW (333 PS) | 6.3 s | 250 km/h (155 mph) |
| Maybach S 500 | 335 kW (455 PS) | 5 s | 250 km/h (155 mph) |
| Maybach S 500 4MATIC | 335 kW (455 PS) | 5 s | 250 km/h (155 mph) |
| Maybach S 560 | 345 kW (469 PS) | 4.9 s | 250 km/h (155 mph) |
| Maybach S 560 4MATIC | 345 kW (469 PS) | 4.9 s | 250 km/h (155 mph) |
| Maybach S 600 | 390 kW (530 PS) | 5 s | 250 km/h (155 mph) |
| Maybach S 650 / (S 680 für chinesischen Markt) | 463 kW (630 PS) | 4.7 s | 250 km/h (155 mph) |
| Maybach S 650 Pullman | 463 kW (630 PS) | 6.5 s | |
| S 350 L / S 320 L | 200 kW (272 PS) | 7.1 s | 250 km/h (155 mph) |
| S 400 L | 245 kW (333 PS) | 6.8 s | 250 km/h (155 mph) |
| S 400 L 4MATIC | 245 kW (333 PS) | 6.8 s | 250 km/h (155 mph) |
| S 500 e L | 325 kW (442 PS) | 5.7 s | 250 km/h (155 mph) |
| S 500 L 4MATIC | 310 kW (422 PS) | 4.9 s | 250 km/h (155 mph) |
| S 300 BlueTEC HYBRID (L) / S 300 h (L) | 150 kW (204 PS) | 7.6 s | 240 km/h (149 mph) |
| S 350 BlueTEC (L) / S 350 d (L) / S 350 CDI L | 190 kW (258 PS) | 6.8 s | 250 km/h (155 mph) |
| S 350 BlueTEC 4MATIC (L) / S 350 d 4 MATIC | 190 kW (258 PS) | 6.8 s | 250 km/h (155 mph) |
| S 350 d (L) | 210 kW (286 PS) | 6 s | 250 km/h (155 mph) |
| S 350 d 4MATIC (L) | 210 kW (286 PS) | 5.8 s | 250 km/h (155 mph) |
| S 400 d (L) | 250 kW (340 PS) | 5.4 s | 250 km/h (155 mph) |
| S 400 d 4MATIC (L) | 250 kW (340 PS) | 5.2 s | 250 km/h (155 mph) |
Source: Mercedes-Benz Baureihe 222, de.wikipedia.org.
History & notable variants
The S-Class has been the premier range for Mercedes-Benz since its official branding in 1972 with the W116 series, which introduced numerous safety features that became standard in automotive design. Over time, the naming and classification of models within the S-Class have evolved to include various body styles and performance variants such as AMG editions.
Dimensions
| Width | 1,899 to 1,915 mm |
| Height | 1,494 to 1,598 mm |
| Kerb weight | 1,925 to 2,335 kg |
Source: Mercedes-Benz Baureihe 222, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Limousine |
| Produced | 2013–2017 |
Trim levels
SESEL
Factory colours
Admiral BlauAlaska WhiteCaspian Black Chroma FlairBritish Racing Green MetallicPolar WhiteDiamond White TricoatBlackBrilliant Silver Metallic (AXALTA 899708)Cavansite Blue MetallicIridium Silver MetallicPalladium Silver MetallicSelenite Gray MetallicCalcite WhiteObsidian Black MetallicAlabaster WhiteHyacinth Red/Designo Cardinal MetallicGlacier WhiteDiamond Silver MetallicLight Ivory
Reliability & owner notes
- Pros: Innovative safety features, flagship status for Mercedes-Benz
- Cons: High cost, limited availability of certain body styles (e.g., coupé and convertible models are not planned successors to W221/W222)
- Common issues: No specific reliability issues mentioned
