Mercedes S-Class Phev R2S side profile — Mercedes S-Class wheel fitment

Mercedes S-Class wheel fitment — Phev R2S

By Torque, AIWheelTech vehicle & fitment specialist · 2018–2020
Mercedes S-Class wheel fitment at a glance — The Mercedes S-Class Phev R2S (2018–2020) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~110 Nm. It accepts ~8.5J–10J wheels at ET13–ET37 front; staggered setups run 9J–11J rear (ET15–ET41).

Overview

The Mercedes-Benz S-Class is a series of full-sized luxury sedans and coupés produced by Mercedes-Benz. The Phev R2S generation, part of the W223 chassis code, represents the latest iteration of this flagship model introduced after 2020. It features advanced drivetrain technologies including plug-in hybrid systems, continuing the S-Class tradition of innovation in safety, comfort, and performance. This generation emphasizes luxury, technology integration, and environmental sustainability with its hybrid powertrain.

Mercedes S-Class wheel fitment

Mercedes S-Class wheel fitment for the Mercedes S-Class Phev R2S (2018–2020): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque110 Nm
Seat typeradius
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8.5J–10JET13–ET37
Rear (staggered)9J–11JET15–ET41

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes S-Class →Get them fitted (UK)

Performance

VariantPower0–62 mphTop speed
Phev R2S

Dimensions

Length5116 mm
Width1899 mm
Height1496 mm
Wheelbase3035 mm

Body styles & production

Body stylesSaloon
Produced2018–2020

Trim levels

Phev R2S

Factory colours

Obsidian Black MetallicBlack Diamond MetallicCashmere MetallicMystic White PearlDesigno Mauritiusblau MetallicChablis MetallicAlmadinschwarz MetallicBlack Opal MetallicBrilliant Emerald MetallicDesigno Silber MetallicDesigno Silver MetallicJade Green MetallicChromaflair MetallicDesigno Chromaflair MetallicMystic Blue PearlDesigno Mocha Black MetallicVaricolor III MetallicChalcedonblau PearlCapri Blue MetallicFlint Gray Metallic

History & notable variants

The Phev R2S is part of a long lineage that began in 1972 with the W116 model, marking the official introduction of the S-Class name. Over decades, it has been at the forefront of automotive technology and luxury, setting standards for safety features such as seatbelt pretensioners. The Phev R2S generation continues this legacy by integrating cutting-edge hybrid technologies while maintaining its position as Mercedes-Benz's flagship sedan.

Reliability & owner notes
