Mercedes Vito (I) W638 side profile — Mercedes V Class (Vito) wheel fitment

Mercedes V Class (Vito) wheel fitment — Vito I W638

By Torque, AIWheelTech vehicle & fitment specialist · 1995–2003
Mercedes V Class (Vito) wheel fitment at a glance — The Mercedes Vito (I) W638 (1995–2003) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~6J–9J wheels at ET9–ET67.

Overview

The Mercedes-Benz Vito (W638) is a mid-sized light commercial vehicle produced by Mercedes-Benz from 1996 to 2003. It was available as a panel van, chassis cab, or multi-purpose vehicle (MPV), carrying cargo or up to eight passengers. Positioned between the larger Sprinter and smaller Citan in the Mercedes lineup, it offered diesel and gasoline engines with front-wheel drive. The Vito Traveliner/V-Class/Viano variant provided passenger accommodations, featuring less van-like characteristics such as a more spacious seating capacity.

Mercedes V Class (Vito) wheel fitment

Mercedes V Class (Vito) wheel fitment for the Mercedes Vito (I) W638 (1995–2003): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSnone

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6J–9JET9–ET67

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes V Class (Vito) →Get them fitted (UK)

UK popularity & demand

~12,773 Mercedes V Class (Vito) range licensed on UK roads — top 13% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 12,773 Mercedes V Class (Vito) range on UK roads, placing it in the top 13% of car models by volume across our fitment database.

That makes Mercedes V Class (Vito) wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
Viano 3.0 CDI TouchShift3.0 L, 6 in-Vdiesel204 hpRWD
Viano 2.2 CDI2.2 L, 4 in-Ldiesel150 hpRWD
Viano 2.2 CDI TouchShift2.2 L, 4 in-Ldiesel150 hpRWD
V 280VR6 engine (Volkswagen)petrol128 hpFWD
Viano 2.0 CDI (revised)2.2 L, 4 in-Ldiesel116 hpRWD
Viano 2.0 CDI TouchShift (revised)2.2 L, 4 in-Ldiesel116 hpRWD
Viano 2.0 CDI2.2 L, 4 in-Ldiesel109 hpRWD
Viano 2.0 CDI TouchShift2.2 L, 4 in-Ldiesel109 hpRWD
V 230, Vito 114M111 E23petrol105 hpFWD
V 200, Vito 113M111 E20petrol95 hpFWD
V 220 CDI, Vito 112 CDIOM611 DE22 LAdiesel90 hpFWD
V 200 CDI, Vito 110 CDIOM611 DE22 LA red.diesel75 hpFWD
V 230 TD, Vito 110 DOM601 D23 LAdiesel72 hpFWD
Vito 108 CDIOM611 DE22 LA red.diesel60 hpFWD
Vito 108 DOM601 D23diesel58 hpFWD

Performance

VariantPower0–62 mphTop speed
Viano 2.0 CDI109 hp17.6 s99 mph
Viano 2.0 CDI TouchShift109 hp17.3 s98 mph
Viano 2.0 CDI (revised)116 hp17.6 s99 mph
Viano 2.0 CDI TouchShift (revised)116 hp17.3 s98 mph
Viano 2.2 CDI150 hp14.9 s112 mph
Viano 2.2 CDI TouchShift150 hp13 s111 mph
Viano 3.0 CDI TouchShift204 hp9.2 s123 mph

Dimensions

Length4600 mm
Width1870 mm
Height1844 mm
Wheelbase3000 mm
Kerb weight2040 kg

Body styles & production

Body stylesPanel van, chassis cab, multi-purpose vehicle (MPV)
Produced1995–2003

Trim levels

VitoViano

Factory colours

Schwarz SolidRavennagelb SolidCalcitgelb SolidMellitgelb Solidbergkristallweiss metArtikwess SolidCarbonschwarz MetallicstrassengelbObsidianschwarz MetallicAnthracyte grey metallic

History & notable variants

The first generation of the Vito was introduced in 1996 and produced until 2003. It received a battery-electric variant, the Vito 108 E, unveiled in July 1996. The vehicle competed with models like the Citroën Jumpy, Peugeot Expert, Volkswagen Transporter, Fiat Scudo, Ford Transit, Hyundai H-1, Opel Vivaro, Renault Trafic, Toyota Hiace, and GAZ Sobol.
