Mercedes V Class (Vito) wheel fitment — Vito Ii 639
Mercedes V Class (Vito) wheel fitment
Mercedes V Class (Vito) wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Mercedes Vito (Ii) 639 (2003–2011).
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | none |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–9J | ET8–ET67 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 12,773 Mercedes V Class (Vito) range on UK roads, placing it in the top 13% of car models by volume across our fitment database.
A parc that size is why Mercedes V Class (Vito) wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Kerb weight | 1,790 to 2,450 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2003–2011 |
