Toyota Aygo wheel fitment — I AB1, /-N, /-MS1
Overview
The Toyota Aygo (AB10/AB20/AB30) is a city car (A-segment) marketed by Toyota mainly in the European market from 2005 to 2014. It was first displayed at the 2005 Geneva International Motor Show and built alongside the related Citroën C1 and Peugeot 107/108 at the TPCA joint venture in Kolín, Czech Republic. The Aygo was available as a three- or five-door hatchback with two engine options: a 1.0L petrol I3 (68 PS) and a 1.4L turbo-diesel I4 (54 PS). It featured front-engine, front-wheel-drive layout and was known for its maneuverability showcased on BBC's Top Gear.
Toyota Aygo wheel fitment
Start with the hub. The Toyota Aygo (I) AB1, /-N, /-MS1 spec table gives the bolt pattern and bore; the second table is the aftermarket window for Toyota Aygo wheel fitment.
| Bolt pattern (PCD) | 4x100 |
| Centre bore | 54.1 mm |
| Bolt / thread | M12x1.5 (bolts) |
| Wheel-bolt torque | 103 Nm |
| Seat type | tapered |
| Factory setup | square |
| Tyre pressure | 32psi |
| Brakes | e11*2001/116*0236*00-10;e11*2007/46*0055*..e11*2007/46*0235*..- incl. Facelift 2012 |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 4.5J–7J | ET15–ET40 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 306,254 Toyota Aygo on UK roads, placing it in the top 1% of car models by volume across our fitment database.
That makes Toyota Aygo wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Kerb weight | 875 to 985 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2005–2014 |
Trim levels
Factory colours
History & notable variants
The Aygo received two facelifts: the first in 2009–2012 with a revised front bumper and rear lights, and the second from 2012 to 2014 incorporating a more angular bumper with daytime running lights. Notable special editions include Aygo Blue (lagoon blue), ckIN2U (collaboration with Calvin Klein), and various limited editions like Easy, Fire, Go!, Ice, Mode, Move, Platinum, + (Plus), Sport, Team, Edition, X-claim, etc.
Reliability & owner notes
- Pros: Competent town car, maneuverable, special editions with unique themes
- Cons: Limited engine options, no diesel variant after 2014
- Common issues: Faulty sticking accelerator pedal recall (2010)
