Toyota Prius wheel fitment — IV XW50
Toyota Prius wheel fitment
Toyota Prius wheel fitment for the Toyota Prius (IV) XW50 (1997–present): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5X100 |
| Centre bore | 54.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Seat type | flat |
| Factory setup | square |
| Brakes | e11*2007/46*2971*..;e13*2007/46*1931*..;e6*2007/46*0339*.. |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–8.5J | ET30–ET50 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 84,839 Toyota Prius on UK roads, placing it in the top 5% of car models by volume across our fitment database.
With that many on the road, Toyota Prius wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Overview
The Toyota Prius (IV) XW50 is a fourth-generation compact liftback produced by Toyota since December 9, 2015. It marks the first use of Toyota's New Global Architecture (TNGA) platform, which offers improved structural rigidity and a lower center of gravity compared to its predecessor. The Prius IV was introduced in Japan before expanding to North America and Europe. This generation includes an all-wheel-drive variant with Toyota's E-Four system, available since late 2018 for the U.S. market. It features updated exterior styling including redesigned headlights and tail lights.
Dimensions
| Length | 4,572 mm |
| Width | 1,760 mm |
| Height | 1,471 mm |
| Wheelbase | 2,700 mm |
Source: Toyota Prius (XW50), en.wikipedia.org.
Body styles & production
| Body styles | 5-door liftback <!-- rear hatch counts as a door --> |
| Produced | 1997–present |
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.8 L 2ZR-FXE I4 (gasoline hybrid) | hybrid |
Source: Toyota Prius (XW50), en.wikipedia.org.
Trim levels
Factory colours
History & notable variants
The fourth-generation Prius made its debut in September 2015 at a press event in Las Vegas. The model was developed alongside the plug-in hybrid variant, the Prius Prime, which became available later in late 2016. In 2018, the U.S. market received an all-wheel-drive option and a mid-generation facelift with refreshed styling elements.
Reliability & owner notes
- Pros: Improved structural rigidity and lower center of gravity; availability of all-wheel drive (E-Four) variant
- Cons: Higher drag coefficient compared to previous generation; smaller cargo volume than its predecessor
- Common issues: No specific reliability issues mentioned
