Toyota RAV4 wheel fitment — I XA10
Toyota RAV4 wheel fitment
Toyota RAV4 wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Toyota RAV4 (I) XA10 (1994–2000).
| Bolt pattern (PCD) | 5x114.3 |
| Centre bore | 60.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Wheel-bolt torque | 105 Nm |
| Seat type | flat |
| Factory setup | square |
| Tyre pressure | 32Psi |
| Brakes | e6*98/14*0070*..,e6*2001/116*0070*..- mit Radhaus- Verbreiterungen |
| TPMS | none |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 7J–9J | ET8–ET45 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Overview
The first generation Toyota RAV4 (XA10 series) was introduced in Japan and Europe in May 1994 and launched in North America in January 1996. It was designed to cater to consumers seeking a vehicle that combined the benefits of SUVs, such as increased cargo space and higher visibility, with the maneuverability of mid-size cars. The RAV4 is credited with popularizing compact crossover vehicles. Available in both three-door (hardtop) and five-door configurations, it offered petrol engines ranging from 2.0L to 2.4L capacities, along with a unique electric variant produced between 1997-2003.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 2.0 L 3S-FE I4 | petrol | |||
| 2.0 L 3S-GE I4 | petrol |
Source: Toyota RAV4, en.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 144,894 Toyota RAV4 on UK roads, placing it in the top 3% of car models by volume across our fitment database.
With that many on the road, Toyota RAV4 wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
History & notable variants
The first generation RAV4 was slightly restyled in 1997 for the 1998 model year, introducing a soft-top three-door version and increasing power output. It received an award as the 1997 Automobile of the Year by Automobile Magazine. In Japan, it was also sold under the name Toyota Vanguard from 2005 to 2016.
Dimensions
| Length | 3,740 to 4,160 mm |
| Width | 1,695 mm |
| Height | 1,646 to 1,661 mm |
| Wheelbase | 2,200 to 2,410 mm |
Source: Toyota RAV4, en.wikipedia.org.
Body styles & production
| Body styles | 3-door SUV (hardtop), 5-door SUV, 3-door convertible SUV (softtop) |
| Produced | 1994–2000 |
Trim levels
Factory colours
Reliability & owner notes
- Pros: Combination of SUV benefits and car-like maneuverability; available in both FWD and AWD configurations
- Cons: Limited production details provided; no specific performance data for all variants
- Common issues: No reliability issues specified
