Toyota RAV4 wheel fitment — V XA50
Overview
The Toyota RAV4 (V) XA50 is part of the compact crossover SUV segment and represents the fifth generation of this iconic vehicle. Introduced in 2018, it was designed to cater to consumers seeking a versatile, practical, and technologically advanced SUV. The RAV4 XA50 is manufactured at various Toyota plants around the world, including Japan, Canada, China, and others. This generation features an all-new platform that enhances driving dynamics and fuel efficiency while offering both front-wheel drive and four-wheel drive options. Notably, it includes a hybrid variant known as the RAV4 Prime, which has gained significant market traction for its performance and environmental benefits.
Toyota RAV4 wheel fitment
Start with the hub. The Toyota RAV4 (V) XA50 spec table gives the bolt pattern and bore; the second table is the aftermarket window for Toyota RAV4 wheel fitment.
| Bolt pattern (PCD) | 5x114.3 |
| Centre bore | 60.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Wheel-bolt torque | 105 Nm |
| Seat type | flat |
| Factory setup | square |
| Brakes | e6*2007/46*0289*..;e13*2007/46*1991*.. |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 7J–9.5J | ET0–ET45 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 144,894 Toyota RAV4 on UK roads, placing it in the top 3% of car models by volume across our fitment database.
With that many on the road, Toyota RAV4 wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1986 cc 2.0 L M20A-FKS I4 | 126 kW (171 PS) | 2018 | ||
| 2487 cc 2.5 L A25A-FKS I4 | 151 kW (205 PS) | 2018 | ||
| 2487 cc 2.5 L A25A-FXS I4 (hybrid) | hybrid | 163 kW (222 PS) | 2018 | |
| 2487 cc 2.5 L A25B-FXS I4 (hybrid, China) | hybrid | 163 kW (222 PS) | 2019 | |
| 2487 cc 2.5 L A25A-FXS I4 (plug-in hybrid) | phev | 225 kW (306 PS) | 2020 |
Source: Toyota RAV4, en.wikipedia.org.
Dimensions
| Length | 4,570 to 4,600 mm |
| Width | 1,855 mm |
| Height | 1,660 mm |
| Wheelbase | 2,690 mm |
| Kerb weight | 1,530 to 1,640 kg |
Source: Toyota RAV4, en.wikipedia.org.
Body styles & production
| Body styles | 5-door SUV |
| Produced | 1994–present |
Trim levels
History & notable variants
The fifth-generation Toyota RAV4 (XA50) was unveiled in 2018, marking a significant evolution from its predecessors with modern styling, advanced safety features, and improved connectivity options. It received positive reception globally, particularly for its hybrid model which won numerous awards including the North American Car of the Year award in 2020. The RAV4 has been continuously updated since its introduction to include minor changes such as new exterior designs and enhanced interior technology.
Reliability & owner notes
- Pros: Advanced hybrid technology; Strong safety ratings; Versatile interior space
- Cons: Limited cargo capacity compared to larger SUVs; Some trims lack premium features
