Toyota Yaris (IV) GR-Sport XPA1F side profile — Toyota Yaris GR-Sport wheel fitment

Toyota Yaris GR-Sport wheel fitment — IV XPA1F

By Torque, AIWheelTech vehicle & fitment specialist · 2020–2026
If you only need the numbers for Toyota Yaris GR-Sport wheel fitment: The Toyota Yaris (IV) GR-Sport XPA1F (2020–2026) uses a 5X100 bolt pattern, 54.1 mm centre bore, M12x1.5 nuts torqued to ~120 Nm. It accepts ~7J–8.5J wheels at ET35–ET50.

Toyota Yaris GR-Sport wheel fitment

Toyota Yaris GR-Sport wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Toyota Yaris (IV) GR-Sport XPA1F (2020–2026).

Bolt pattern (PCD)5X100
Centre bore54.1 mm
Bolt / threadM12x1.5 (nuts)
Wheel-bolt torque120 Nm
Seat typeflat
Factory setupsquare
Brakese6*2007/46*0437*..;e13*2007/46*2342*..;e13*2018/858*00004*..
TPMSdirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front7J–8.5JET35–ET50

As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Toyota Yaris GR-Sport →Get them fitted (UK)

Body styles & production

Produced2020–2026

Factory colours

Super White SolidSilver MetallicGrey MetallicBlack Mica SolidGreyish Blue SolidDark Blue Metallicprecious black met.t3 ruby flare prl.platinum white prl.Oxide Bronze MetallicEmotional Red Pearl
