Vauxhall Astra wheel fitment — Astra-J P-J, -/V, /SW
The Vauxhall Astra-J P-J, -/V, /SW (2010–2016) uses a 5x105 bolt pattern, 56.6 mm centre bore, M12x1.5 nuts torqued to ~120 Nm. It accepts ~6.5J–9J wheels at ET25–ET46. That is the short version of Vauxhall Astra wheel fitment; the full picture is below.
Vauxhall Astra wheel fitment
Everything below is what the fit-check uses for Vauxhall Astra wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Vauxhall Astra-J P-J, -/V, /SW.
| Bolt pattern (PCD) | 5x105 |
| Centre bore | 56.6 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–9J | ET25–ET46 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.4 (ecoFLEX) | 1,398 cc, A14XEL | petrol | 64 kW (87 PS) | 2009 to 2013 |
| 1.4 (ecoFLEX) | 1,398 cc, A14XER | petrol | 74 kW (100 PS) | 2009 to 2013 |
| 1.6 (ecoFLEX) | 1,598 cc, A16XER | petrol | 85 kW (115 PS) | 2009 to 2018 |
| 1.4 Turbo (ecoFLEX) | 1,364 cc, A14NEL | petrol | 88 kW (120 PS) | 2010 to 2018 |
| 1.4 Turbo (ecoFLEX) | 1,364 cc, A14NET | petrol | 103 kW (140 PS) | 2009 to 2018 |
| 1.4 LPG Turbo ecoFLEX | 1,364 cc, A14NET | petrol | 103 kW (140 PS) | 2012 to 2018 |
| 1.6 ECOTEC Direct Injection Turbo ecoFLEX | 1,598 cc, A16XHT | petrol | 125 kW (170 PS) | 2012 to 2018 |
| 1.6 Turbo | 1,598 cc, A16LET | petrol | 132 kW (180 PS) | 2009 to 2012 |
| 1.6 ECOTEC Direct Injection Turbo ecoFLEX | 1,598 cc, A16SHT | petrol | 147 kW (200 PS) | 2013 to 2018 |
| OPC | 1,998 cc, A20NFT/B20NFT | petrol | 206 kW (280 PS) | 2012 to 2018 |
| 1.3 CDTI (ecoFLEX) | 1,248 cc, A13DTE | diesel | 70 kW (95 PS) | 2009 to 2013 |
| 1.7 CDTI | 1,686 cc, A17DTJ | diesel | 81 kW (110 PS) | 2009 to 2011 |
| 1.7 CDTI (ecoFLEX) | 1,686 cc, A17DTC, A17DTE | diesel | 81 kW (110 PS) | 2011 to 2014 |
| 1.6 CDTI (ecoFLEX) | 1,598 cc, B16DTL | diesel | 81 kW (110 PS) | 2014 to 2018 |
| 1.7 CDTI | 1,686 cc, A17DTR | diesel | 92 kW (125 PS) | 2009 to 2012 |
| 1.7 CDTI (ecoFLEX) | 1,686 cc, A17DTF, A17DTS | diesel | 96 kW (130 PS) | 2011 to 2014 |
| 1.6 CDTI (ecoFLEX) | 1,598 cc, B16DTH | diesel | 100 kW (136 PS) | 2014 to 2018 |
| 2.0 CDTI (ecoFLEX) | 1,956 cc, A20DTH | diesel | 118 kW (160 PS) | 2009 to 2011 |
| 2.0 CDTI (ecoFLEX) | 1,956 cc, A20DTH | diesel | 121 kW (165 PS) | 2011 to 2015 |
| 2.0 BiTurbo CDTI | 1,956 cc, A20DTR | diesel | 143 kW (195 PS) | 2012 to 2015 |
Source: Opel Astra J, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.4 (ecoFLEX) | 64 kW (87 PS) | 15.1 s | 168 km/h (104 mph) |
| 1.4 (ecoFLEX) | 74 kW (100 PS) | 13.9 s | 178 km/h (111 mph) |
| 1.6 (ecoFLEX) | 85 kW (115 PS) | 11.7 to 13.3 s | 182 to 188 km/h (113 to 117 mph) |
| 1.4 Turbo (ecoFLEX) | 88 kW (120 PS) | 192 km/h (119 mph) | |
| 1.4 Turbo (ecoFLEX) | 103 kW (140 PS) | 9.9 to 10.2 s | 200 to 202 km/h (124 to 126 mph) |
| 1.4 LPG Turbo ecoFLEX | 103 kW (140 PS) | 10.8 s | 200 km/h (124 mph) |
| 1.6 ECOTEC Direct Injection Turbo ecoFLEX | 125 kW (170 PS) | 8.7 s | 220 km/h (137 mph) |
| 1.6 Turbo | 132 kW (180 PS) | 8.5 to 9 s | 211 to 221 km/h (131 to 137 mph) |
| 1.6 ECOTEC Direct Injection Turbo ecoFLEX | 147 kW (200 PS) | 7.9 s | 230 km/h (143 mph) |
| OPC | 206 kW (280 PS) | 6 s | 250 km/h (155 mph) |
| 1.3 CDTI (ecoFLEX) | 70 kW (95 PS) | 14.5 s | 175 km/h (109 mph) |
| 1.7 CDTI | 81 kW (110 PS) | 12.6 s | 181 km/h (112 mph) |
| 1.7 CDTI (ecoFLEX) | 81 kW (110 PS) | 12.3 to 12.5 s | 186 to 188 km/h (116 to 117 mph) |
| 1.6 CDTI (ecoFLEX) | 81 kW (110 PS) | 12 s | 186 km/h (116 mph) |
| 1.7 CDTI | 92 kW (125 PS) | 11.5 s | 195 km/h (121 mph) |
| 1.7 CDTI (ecoFLEX) | 96 kW (130 PS) | 10.6 to 11.2 s | 198 to 201 km/h (123 to 125 mph) |
| 1.6 CDTI (ecoFLEX) | 100 kW (136 PS) | 10.3 s | 200 km/h (124 mph) |
| 2.0 CDTI (ecoFLEX) | 118 kW (160 PS) | 9 to 9.2 s | 209 to 215 km/h (130 to 134 mph) |
| 2.0 CDTI (ecoFLEX) | 121 kW (165 PS) | 9 to 9.2 s | 209 to 215 km/h (130 to 134 mph) |
| 2.0 BiTurbo CDTI | 143 kW (195 PS) | 7.8 s | 226 km/h (140 mph) |
Source: Opel Astra J, de.wikipedia.org.
UK popularity & demand
~552,054 Vauxhall Astra licensed on UK roads — top 1% of models by volume.
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 552,054 Vauxhall Astra on UK roads, placing it in the top 1% of car models by volume across our fitment database.
A parc that size is why Vauxhall Astra wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 4,419 to 4,698 mm |
| Width | 1,814 to 1,840 mm |
| Height | 1,482 to 1,535 mm |
| Wheelbase | 2,685 to 2,695 mm |
| Kerb weight | 1,362 to 1,646 kg |
Source: Opel Astra J, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Kombilimousine, Limousine, Kombi |
| Produced | 2010–2016 |
Factory colours
Lightsilber MetallicPannacotta / Beige MetallicSaphirschwarz Black MetallicUltrablau Pearl MetallicMidnight Black MetallicPowerrot/Red SolidRoyal Blue SolidMetro Blue MetallicSwitchblade / Sovereign Silver MetallicTechnical Grey MetallicSchwarz II SolidIceberg / Green MetallicOriental Blue MetallicWaterworld Blue MetallicSilky Shadow Green MetallicSchneeweiss / Olympic / Summit White SolidGar Carbon Flash / Grey Metallicgcs velvet red met.Misty Lake / Blue MetallicCarbon Flash / Grey Metallic
