Volkswagen Amarok wheel fitment — I 2H, 2HS2
Overview
The Volkswagen Amarok is a mid-size pickup truck produced by German automaker Volkswagen Commercial Vehicles since 2010. It was first presented in General Pacheco, Argentina, on January 7, 2010. The project began in 2005 with the intent to build a robust and off-road capable vehicle. The Amarok is available as single cab or double cab variants, with either rear-wheel drive or four-wheel-drive options (4Motion). It features turbocharged petrol engines and diesel engines, including a range of TDI units from Volkswagen's Transporter (T5) and later models include the 3.0L V6 TDI engine introduced in 2017.
History & notable variants
The first-generation Amarok was launched in Argentina and then expanded to other markets such as Europe, South America, Australia, and others. It underwent a facelift in 2016 with significant changes including the introduction of the new 3.0L V6 TDI engine. A second facelift occurred in 2024 for the Argentine market, featuring design cues from the Mk2 Amarok and an updated interior.
Volkswagen Amarok wheel fitment
Everything below is what the fit-check uses for Volkswagen Amarok wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Volkswagen Amarok (I) 2H, 2HS2.
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 65.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–9.5J | ET30–ET62 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 90 kW (122 PS) | RWD, 2010 to 2012 |
| 2.0 TDI 4Motion | VW EA189, 1,968 cc | diesel | 90 kW (122 PS) | 4MOTION, 2010 to 2012 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 103 kW (140 PS) | RWD, 2012 to 2016 |
| 2.0 TDI 4Motion | VW EA189, 1,968 cc | diesel | 103 kW (140 PS) | 4MOTION, 2012 to 2016 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 120 kW (163 PS) | RWD, 2010 to 2012 |
| 2.0 TDI 4Motion | VW EA189, 1,968 cc | diesel | 120 kW (163 PS) | 4MOTION, 2010 to 2012 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 132 kW (180 PS) | RWD, 2012 to 2016 |
| 2.0 TDI 4Motion | VW EA189, 1,968 cc | diesel | 132 kW (180 PS) | 4MOTION, 2011 to 2016 |
| 3.0 TDI | VW EA897 evo, 2,967 cc | diesel | 120 kW (163 PS) | RWD, 2017 to 2020 |
| 3.0 TDI 4Motion | VW EA897 evo, 2,967 cc | diesel | 150 kW (204 PS) | 4MOTION, 2016 to 2020 |
| 3.0 TDI 4Motion | VW EA897 evo, 2,967 cc | diesel | 165 kW (224 PS) | 4MOTION, 2016 to present |
| 3.0 TDI 4Motion | VW EA897 evo, 2,967 cc | diesel | 190 kW (258 PS) | 4MOTION, 2018 to present |
| 2.0 TSI | Vierzylinder-Ottomotor in Reihenbauart, Direkt­einspritzung, 1,984 cc | petrol | 118 kW (160 PS) | RWD, 2012 to 2020 |
Source: VW Amarok I, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 2.0 TDI | 90 kW (122 PS) | 13.5 s | 163 km/h (101 mph) |
| 2.0 TDI 4Motion | 90 kW (122 PS) | 13.7 s | 161 km/h (100 mph) |
| 2.0 TDI | 103 kW (140 PS) | 12.6 to 13.3 s | 163 to 169 km/h (101 to 105 mph) |
| 2.0 TDI 4Motion | 103 kW (140 PS) | 12.6 to 13.5 s | 161 to 167 km/h (100 to 104 mph) |
| 2.0 TDI | 120 kW (163 PS) | 10.8 s | 182 km/h (113 mph) |
| 2.0 TDI 4Motion | 120 kW (163 PS) | 11.1 s | 181 km/h (112 mph) |
| 2.0 TDI | 132 kW (180 PS) | 10 to 10.7 s | 178 to 184 km/h (111 to 114 mph) |
| 2.0 TDI 4Motion | 132 kW (180 PS) | 10.3 to 11 s | 177 to 179 km/h (110 to 111 mph) |
| 3.0 TDI | 120 kW (163 PS) | 9.6 to 10 s | 171 to 180 km/h (106 to 112 mph) |
| 3.0 TDI 4Motion | 150 kW (204 PS) | 8.3 to 9.2 s | 182 to 193 km/h (113 to 120 mph) |
| 3.0 TDI 4Motion | 165 kW (224 PS) | 7.9 to 8.2 s | 185 to 193 km/h (115 to 120 mph) |
| 3.0 TDI 4Motion | 190 kW (258 PS) | 7.3 to 7.6 s | 199 to 207 km/h (124 to 129 mph) |
Source: VW Amarok I, de.wikipedia.org.
Dimensions
| Length | 5,191 to 5,254 mm |
| Width | 1,944 to 1,954 mm |
| Height | 1,834 to 1,878 mm |
| Wheelbase | 3,090 to 3,095 mm |
| Kerb weight | 2,095 to 2,421 kg |
Source: VW Amarok I, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Pick-up |
| Produced | 2010–present |
| Units produced | 830,000 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Robust build quality, strong off-road capabilities, wide range of engine options
- Cons: Higher price point compared to competitors, limited availability in some markets
- Common issues: None reported
