Volkswagen Cross Touran wheel fitment — I 1T, 1t
Overview
The Volkswagen Cross Touran (I) 1T is the first generation of the compact MPV, manufactured by Volkswagen from December 2002 to December 2016. It was based on the PQ35 platform and shared its underpinnings with the Volkswagen Golf Mk5. The vehicle offered a five or seven-seat configuration and featured electro-mechanical steering as an industry-first. A facelift in 2006 introduced cosmetic changes, including redesigned headlights and a refreshed front grille. In late 2010, it received another update to match the newer Golf VI aesthetics.
History & notable variants
The Cross Touran was first unveiled at the Bologna Motor Show in December 2006 as a crossover variant of the standard Touran. It featured distinctive styling elements such as 17-inch alloy wheels and plastic guards that gave it an off-road appearance, along with an optional higher suspension setup. The second facelift in August 2010 brought the Cross Touran up to date visually with the Golf VI.
Volkswagen Cross Touran wheel fitment
Everything below is what the fit-check uses for Volkswagen Cross Touran wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Volkswagen Cross Touran (I) 1T, 1t.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–8.5J | ET30–ET50 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.4 TSI | VW EA111, 1,390 cc, Motorkenndaten | petrol | 103 kW (140 PS) | FWD, 2006 to 2009 |
| 1.4 TSI | VW EA111, 1,390 cc, Motorkenndaten | petrol | 103 kW (140 PS) | FWD, 2009 to 2010 |
| 1.4 TSI EcoFuel | VW EA111, 1,390 cc, Motorkenndaten | petrol | 110 kW (150 PS) | FWD, 2009 to 2010 |
| 1.4 TSI | VW EA111, 1,390 cc, Motorkenndaten | petrol | 125 kW (170 PS) | FWD, 2007 to 2010 |
| 1.6 | VW EA113, 1,595 cc, Motorkenndaten | petrol | 75 kW (102 PS) | FWD, 2003 to 2010 |
| 1.6 FSI | VW EA111, 1,598 cc, Motorkenndaten | petrol | 85 kW (115 PS) | FWD, 2003 to 2006 |
| 2.0 EcoFuel | VW EA113, 1,984 cc, Motorkenndaten | petrol | 80 kW (109 PS) | FWD, 2006 to 2009 |
| 2.0 FSI | VW EA113, 1,984 cc, Motorkenndaten | petrol | 110 kW (150 PS) | FWD, 2003 to 2006 |
| 1.9 TDI | VW EA188, 1,896 cc, Motorkenndaten | diesel | 66 kW (90 PS) | FWD, 2004 to 2010 |
| 1.9 TDI (DPF) | VW EA188, 1,896 cc, Motorkenndaten | diesel | 66 kW (90 PS) | FWD, 2005 to 2010 |
| 1.9 TDI | VW EA188, 1,896 cc, Motorkenndaten | diesel | 74 kW (100 PS) | FWD, 2003 to 2004 |
| 1.9 TDI | VW EA188, 1,896 cc, Motorkenndaten | diesel | 77 kW (105 PS) | FWD, 2003 to 2010 |
| 1.9 TDI (DPF) | VW EA188, 1,896 cc, Motorkenndaten | diesel | 77 kW (105 PS) | FWD, 2005 to 2010 |
| 1.9 TDI (DPF) BlueMotion | VW EA188, 1,896 cc, Motorkenndaten | diesel | 77 kW (105 PS) | FWD, 2008 to 2010 |
| 2.0 TDI (DPF) | VW EA188, 1,968 cc, Motorkenndaten | diesel | 77 kW (105 PS) | FWD, 2008 to 2010 |
| 2.0 TDI | VW EA188, 1,968 cc, Motorkenndaten | diesel | 100 kW (136 PS) | FWD, 2003 to 2004 |
| 2.0 TDI | VW EA188, 1,968 cc, Motorkenndaten | diesel | 103 kW (140 PS) | FWD, 2004 to 2010 |
| 2.0 TDI (DPF) | VW EA188, 1,968 cc, Motorkenndaten | diesel | 103 kW (140 PS) | FWD, 2005 to 2010 |
| 2.0 TDI (DPF) | VW EA188, 1,968 cc, Motorkenndaten | diesel | 125 kW (170 PS) | FWD, 2006 to 2010 |
| 1.2 TSI | VW EA111, 1,197 cc, Motorkenndaten | petrol | 77 kW (105 PS) | FWD, 2010 to present |
| 1.2 TSI BlueMotion Technology | VW EA111, 1,197 cc, Motorkenndaten | petrol | 77 kW (105 PS) | FWD, 2010 to present |
| 1.4 TSI | VW EA111, 1,390 cc, Motorkenndaten | petrol | 103 kW (140 PS) | FWD, 2010 to 2012 |
| 1.4 TSI | VW EA111, 1,390 cc, Motorkenndaten | petrol | 103 kW (140 PS) | FWD, 2012 to present |
| 1.4 TGI EcoFuel | VW EA111, 1,390 cc, Motorkenndaten | petrol | 110 kW (150 PS) | FWD, 2010 to present |
| 1.4 TSI | VW EA111, 1,390 cc, Motorkenndaten | petrol | 125 kW (170 PS) | FWD, 2010 to present |
| 1.6 TDI DPF | VW EA189 *, 1,598 cc, Motorkenndaten | diesel | 66 kW (90 PS) | FWD, 2010 to 2011 |
| 1.6 TDI DPF | VW EA189 *, 1,598 cc, Motorkenndaten | diesel | 77 kW (105 PS) | FWD, 2010 to 2015 |
| 1.6 TDI DPF BlueMotion Technology | VW EA189 *, 1,598 cc, Motorkenndaten | diesel | 77 kW (105 PS) | FWD, 2010 to 2015 |
| 2.0 TDI DPF | VW EA189 *, 1,968 cc, Motorkenndaten | diesel | 103 kW (140 PS) | FWD, 2010 to 2015 |
| 2.0 TDI DPF BlueMotion Technology | VW EA189 *, 1,968 cc, Motorkenndaten | diesel | 103 kW (140 PS) | FWD, 2010 to 2015 |
| 2.0 TDI DPF | VW EA189 *, 1,968 cc, Motorkenndaten | diesel | 125 kW (170 PS) | FWD, 2010 to 2013 |
| 2.0 TDI DPF | VW EA189 *, 1,968 cc, Motorkenndaten | diesel | 130 kW (177 PS) | FWD, 2013 to 2015 |
Source: VW Touran I, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.4 TSI | 103 kW (140 PS) | 9.8 s | 200 km/h (124 mph) |
| 1.4 TSI | 103 kW (140 PS) | 9.7 to 9.8 s | 198 to 200 km/h (123 to 124 mph) |
| 1.4 TSI EcoFuel | 110 kW (150 PS) | 10.1 s | 203 km/h (126 mph) |
| 1.4 TSI | 125 kW (170 PS) | 8.5 s | 212 km/h (132 mph) |
| 1.6 | 75 kW (102 PS) | 12.9 s | 179 km/h (111 mph) |
| 1.6 FSI | 85 kW (115 PS) | 11.9 to 13.2 s | 182 to 186 km/h (113 to 116 mph) |
| 2.0 EcoFuel | 80 kW (109 PS) | 13.5 s | 180 km/h (112 mph) |
| 2.0 FSI | 110 kW (150 PS) | 10.4 to 11.2 s | 200 to 201 km/h (124 to 125 mph) |
| 1.9 TDI | 66 kW (90 PS) | 14.9 s | 171 km/h (106 mph) |
| 1.9 TDI (DPF) | 66 kW (90 PS) | 14.9 s | 171 km/h (106 mph) |
| 1.9 TDI | 74 kW (100 PS) | 13.5 s | 177 km/h (110 mph) |
| 1.9 TDI | 77 kW (105 PS) | 13.2 s | 177 to 179 km/h (110 to 111 mph) |
| 1.9 TDI (DPF) | 77 kW (105 PS) | 13.2 s | 177 to 179 km/h (110 to 111 mph) |
| 1.9 TDI (DPF) BlueMotion | 77 kW (105 PS) | 13 s | 182 km/h (113 mph) |
| 2.0 TDI (DPF) | 77 kW (105 PS) | 178 to 180 km/h (111 to 112 mph) | |
| 2.0 TDI | 100 kW (136 PS) | 10.6 s | 197 km/h (122 mph) |
| 2.0 TDI | 103 kW (140 PS) | 10.2 s | 198 to 200 km/h (123 to 124 mph) |
| 2.0 TDI (DPF) | 103 kW (140 PS) | 10.2 s | 198 to 200 km/h (123 to 124 mph) |
| 2.0 TDI (DPF) | 125 kW (170 PS) | 9 to 9.1 s | 212 to 214 km/h (132 to 133 mph) |
| 1.2 TSI | 77 kW (105 PS) | 11.9 s | 185 km/h (115 mph) |
| 1.2 TSI BlueMotion Technology | 77 kW (105 PS) | 11.9 s | 188 km/h (117 mph) |
| 1.4 TSI | 103 kW (140 PS) | 9.5 s | 202 km/h (126 mph) |
| 1.4 TSI | 103 kW (140 PS) | 9.5 s | 202 km/h (126 mph) |
| 1.4 TGI EcoFuel | 110 kW (150 PS) | 10.2 s | 204 km/h (127 mph) |
| 1.4 TSI | 125 kW (170 PS) | 8.5 s | 213 km/h (132 mph) |
| 1.6 TDI DPF | 66 kW (90 PS) | 14.7 s | 174 km/h (108 mph) |
| 1.6 TDI DPF | 77 kW (105 PS) | 12.8 s | 183 km/h (114 mph) |
| 1.6 TDI DPF BlueMotion Technology | 77 kW (105 PS) | 12.8 s | 186 km/h (116 mph) |
| 2.0 TDI DPF | 103 kW (140 PS) | 9.9 s | 199 to 201 km/h (124 to 125 mph) |
| 2.0 TDI DPF BlueMotion Technology | 103 kW (140 PS) | 9.9 s | 201 to 203 km/h (125 to 126 mph) |
| 2.0 TDI DPF | 125 kW (170 PS) | 8.9 s | 213 km/h (132 mph) |
| 2.0 TDI DPF | 130 kW (177 PS) | 8.8 s | 214 km/h (133 mph) |
Source: VW Touran I, de.wikipedia.org.
Dimensions
| Length | 4,391 to 4,407 mm |
| Width | 1,794 to 1,799 mm |
| Height | 1,620 to 1,682 mm |
| Wheelbase | 2,678 mm |
| Kerb weight | 1,436 to 1,710 kg |
Source: VW Touran I, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Kombi |
| Produced | 2002–2026 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Electro-mechanical steering, EURO 4 compliant engines, improved safety features
- Cons: Limited third-row space for adults, no removable seats in cargo area
