Volkswagen Golf Plus 1KP side profile — Volkswagen Golf Plus wheel fitment

Volkswagen Golf Plus wheel fitment — 1KP

By Torque, AIWheelTech vehicle & fitment specialist · 2004–2022
Volkswagen Golf Plus wheel fitment at a glance — The Volkswagen Golf Plus 1KP (2004–2022) uses a 5x112 bolt pattern, 57.1 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~6J–9J wheels at ET35–ET54.

Overview

The Volkswagen Golf Plus is a car that was manufactured by Volkswagen between 2004 and 2014. It has been variously described as a hatchback, a compact multi-purpose vehicle (MPV), or a combination of the two. It was developed as a taller alternative to the Golf hatchback and positioned below the seven-seater Touran in Volkswagen's MPV category. The car is based on the Golf Mk5, rides on the PQ35 platform, and was accompanied by a crossover-styled variant called the Volkswagen CrossGolf in 2006. Throughout its life cycle, it has been sold alongside the Golf Mk5 and the Golf Mk6 for its final two years.

Volkswagen Golf Plus wheel fitment

Volkswagen Golf Plus wheel fitment for the Volkswagen Golf Plus 1KP (2004–2022): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore57.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6J–9JET35–ET54

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Volkswagen Golf Plus →Get them fitted (UK)

Engines & drivetrain

VariantEngineFuelPowerDrive
2.0 FSI1,984 cc I4petrol150 hpFWD
2.0 TDI (PD)1,968 cc I4diesel140 hpFWD
1.4 TSI1,390 cc I4petrol122 hpFWD
1.6 FSI1,598 cc I4petrol115 hpFWD
2.0 TDI (CR)1,968 cc I4diesel110 hpFWD
1.2 TSI1,197 cc I4petrol105 hpFWD
1.61,595 cc I4petrol102 hpFWD
1.6 MultiFuel1,595 cc I4102 hpFWD
1.6 BiFuel1,595 cc I498 hpFWD
1.6 TDI (CR)1,598 cc 14diesel90 hpFWD
1.9 TDI (PD)1,896 cc I4diesel90 hpFWD
1.41,390 cc I4petrol75 hpFWD

Performance

VariantPower0–62 mphTop speed
TSI 1.4L160 hp
TDI 1.9L105 hp

Dimensions

Length4204 mm
Width1759 mm
Height1580 mm
Wheelbase2578 mm
Kerb weight1293 kg

Body styles & production

Body styles5-door hatchback
Produced2004–2022

Trim levels

SEDune (CrossGolf variant)

Factory colours

REFLEXSILBER-MET.DEEPBLACK-MET.CANDYWEISSSHADOW BLUE-MET.BLACK MAGIC-MET.TORNADOROTAmaryllisrot MetallicShark Blue MetallicSunsetred MetallicKaschmirbraun MetallicSilver Leaf MetallicReflexsilber MetallicSchwarz SolidCandy White SolidBlack Magic Pearl

History & notable variants

In December 2004, the Golf Plus was presented to the public at the Bologna Motor Show. In December 2008, a facelifted version was revealed at the same show, featuring revised front-end styling with horizontally aligned band front grille and new headlights with daytime running lights, aligning its design more closely with the Golf Mk6. The CrossGolf variant was introduced in 2006 at the Paris Motor Show.
