Volkswagen Golf Sportsvan AUV, 1KM side profile — Volkswagen Golf Sportsvan wheel fitment

Volkswagen Golf Sportsvan wheel fitment — AUV, 1KM

By Torque, AIWheelTech vehicle & fitment specialist · 2014–2020
Volkswagen Golf Sportsvan wheel fitment at a glance — The Volkswagen Golf Sportsvan AUV, 1KM (2014–2020) uses a 5x112 bolt pattern, 57.1 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~6J–8.5J wheels at ET32–ET52.

Overview

The Volkswagen Golf Sportsvan, also known as the Golf SV, is a five-door compact MPV designed and produced by Volkswagen from 2014 to 2020. It was introduced at the Frankfurt Motor Show in 2013 as a concept car and positioned below the seven-seater Touran in the company's lineup. The Sportsvan is derived from the Golf Mk7 and built on the MQB platform, sharing assembly facilities with the standard Golf hatchback in Wolfsburg, Germany. Compared to its predecessor, the Golf Plus, it offers increased luggage capacity and enhanced safety features such as a blind spot monitor and automatic post-collision braking system.

Volkswagen Golf Sportsvan wheel fitment

Volkswagen Golf Sportsvan wheel fitment for the Volkswagen Golf Sportsvan AUV, 1KM (2014–2020): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore57.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6J–8.5JET32–ET52

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Volkswagen Golf Sportsvan →Get them fitted (UK)

Engines & drivetrain

VariantEngineFuelPowerDrive
1.4L TSI I4 150 PS1.4L Turbocharged Inline-4 Petrol Enginepetrol150 hpFWD
2.0L TDI I4 150 PS2.0L Turbocharged Inline-4 Diesel Enginediesel150 hpFWD
1.4L TSI I4 125 PS1.4L Turbocharged Inline-4 Petrol Enginepetrol125 hpFWD
1.6L TDI I4 110 PS1.6L Turbocharged Inline-4 Diesel Enginediesel110 hpFWD
1.2L TSI I4 105 PS1.2L Turbocharged Inline-4 Petrol Enginepetrol105 hpFWD
1.6L TDI I4 90 PS1.6L Turbocharged Inline-4 Diesel Enginediesel90 hpFWD
1.2L TSI I4 85 PS1.2L Turbocharged Inline-4 Petrol Enginepetrol85 hpFWD
1.0L TSI I31.0L Turbocharged Inline-3 Petrol Enginepetrol75 hpFWD

Performance

VariantPower0–62 mphTop speed
1.4 TSI 150 PS150 hp

Dimensions

Length4338 mm
Width1807 mm
Height1578 mm
Wheelbase2685 mm
Kerb weight1327 kg

Body styles & production

Body stylesMulti-purpose vehicle (MPV)
Produced2014–2020

Trim levels

HighlineBlueMotion Technology

Factory colours

REFLEXSILBER-MET.DEEPBLACK-MET.BLANC PURURANOGRAUTORNADOROTBLEU NUIT-MET.

History & notable variants

The Golf Sportsvan received notable recognition including the Red Dot Design Award and IF Product Design Award in 2015. It underwent a facelift in 2018, introducing minor aesthetic changes but maintaining its core features and functionality.
