Volkswagen Golf (Vi) 1K side profile — Volkswagen Golf wheel fitment

Volkswagen Golf wheel fitment — Vi 1K

By Torque, AIWheelTech vehicle & fitment specialist · 2003–2009
Volkswagen Golf wheel fitment at a glance: The Volkswagen Golf (Vi) 1K (2003–2009) uses a 5x112 bolt pattern, 57.1 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~6J–9J wheels at ET32–ET54.

Overview

The Volkswagen Golf Mk5 (Vi) is a compact car produced from 2003 to 2009, marking the fifth generation of this iconic model. It was introduced in Europe in autumn 2003 and reached the UK market early 2004. In North America, it returned with the Rabbit nameplate for the 2006 model year. The Mk5 is based on Volkswagen's PQ35 platform and features a range of engines including turbocharged petrol and diesel options. Notable variants include the GTI, R32, and Fast marketing campaign editions. It was available in various body styles such as hatchback and sedan (marketed as Jetta).

Volkswagen Golf wheel fitment

Start with the hub. The Volkswagen Golf (Vi) 1K spec table gives the bolt pattern and bore; the second table is the aftermarket window for Volkswagen Golf wheel fitment.

Bolt pattern (PCD)5x112
Centre bore57.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6J–9JET32–ET54

Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.

Browse wheels that fit a Volkswagen Golf →Get them fitted (UK)

UK popularity & demand

~944,531 Volkswagen Golf licensed on UK roads — top 1% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 944,531 Volkswagen Golf on UK roads, placing it in the top 1% of car models by volume across our fitment database.

With that many on the road, Volkswagen Golf wheel fitment is a spec fitters see constantly. We keep it current for that reason.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive, years
1.4VW EA111, 1,390 cc, CGGApetrol59 kW (80 PS)FWD, 2008 to 2013
1.2 TSIVW EA111, 1,197 cc, CBZA, CBZBpetrol63 kW (86 PS)FWD, 2010 to 2012
1.6VW EA113, 1,595 cc, BSE, BSF, CCSApetrol75 kW (102 PS)FWD, 2008 to 2010
1.2 TSIVW EA111, 1,197 cc, CBZBpetrol77 kW (105 PS)FWD, 2009 to 2012
1.2 TSI BlueMotion TechnologyVW EA111, 1,197 cc, CBZBpetrol77 kW (105 PS)FWD, 2009 to 2012
1.4 TSIVW EA111, 1,390 cc, CAXApetrol90 kW (122 PS)FWD, 2008 to 2012
1.4 TSIVW EA111, 1,390 cc, CAVDpetrol118 kW (160 PS)FWD, 2008 to 2012
1.8 T (Aktionsmodell)VW EA888, 1,798 cc, CDAApetrol118 kW (160 PS)FWD, 2009 to 2010
GTIVW EA888, 1,984 cc, CCZBpetrol155 kW (211 PS)FWD, 2009 to 2012
GTI „Edition 35“VW EA113, 1,984 cc, CDLGpetrol173 kW (235 PS)FWD, 2011 to 2012
RVW EA113, 1,984 cc, CDLFpetrol199 kW (270 PS)4MOTION, 2009 to 2012
1.6 BiFuelVW EA113, 1,595 cc, CHGApetrol75 kW (102 PS)FWD, 2009 to 2012
2.52,480 cc, BGQ,CBUA,CBTApetrol127 kW (172 PS)FWD
1.6 TDIVW EA189, 1,598 cc, CAYBdiesel66 kW (90 PS)FWD, 2009 to 2013
1.6 TDIVW EA189, 1,598 cc, CAYCdiesel77 kW (105 PS)FWD or 4MOTION, 2009 to 2012
1.6 TDI BlueMotion TechnologyVW EA189, 1,598 cc, CAYCdiesel77 kW (105 PS)FWD, 2009 to 2012
1.6 TDI BlueMotionVW EA189, 1,598 cc, CAYCdiesel77 kW (105 PS)FWD, 2009 to 2012
2.0 TDIVW EA189, 1,968 cc, CBDC, CLCA, CUUAdiesel81 kW (110 PS)FWD, 2008 to 2009
2.0 TDI (119g)VW EA189, 1,968 cc, CBDC, CLCA, CUUAdiesel81 kW (110 PS)FWD, 2008 to 2009
2.0 TDIVW EA189, 1,968 cc, CBAB, CFFB, CJAA, CFHCdiesel103 kW (140 PS)FWD, 2008 to 2012
2.0 TDI 4MotionVW EA189, 1,968 cc, CBAB, CFFB, CJAA, CFHCdiesel103 kW (140 PS)4MOTION, 2008 to 2012
GTDVW EA189, 1,968 cc, CBBB, CFGBdiesel125 kW (170 PS)FWD, 2009 to 2012

Source: VW Golf VI, de.wikipedia.org.

Dimensions

Length4,199 to 4,534 mm
Width1,786 to 2,048 mm
Height1,461 to 1,504 mm
Wheelbase2,578 mm
Kerb weight1,217 to 1,541 kg

Source: VW Golf VI, de.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body stylesKombilimousine, Kombi, Cabriolet
Produced2003–2009

Trim levels

BaseGTIR32

Factory colours

SurfblauJazz Blue PearlImola YellowStormbeige MetallicSilverstone Gray PearlPlatinum Gray MetallicFrescogruen MetallicSage Green MetallicSchwarzGreen Collection PearlMercatoblau MetallicDeep Blue PearlSuede Silver PearlIndigo Blue PearlSilver Arrow MetallicReflex Silver MetallicInky Blue PearlOceanicgruen MetallicBaltic Green PearlMatchstick Red Pearl

History & notable variants

The Mk5 generation saw significant improvements over its predecessor with enhanced performance models like the 1.4-litre TSI engine and the introduction of the R32 featuring a 3.2-litre VR6 engine. The GTI version received positive reviews for its driving dynamics, though it was criticized for road noise and fuel economy. In Mexico, only the GTI variant was available.
