Volkswagen Golf wheel fitment — Vii R AU
Overview
The Volkswagen Golf (Vii) R AU is part of the seventh generation of the popular compact car, produced from 2012 to 2019. Built on the MQB platform shared with other Audi, SEAT, and Škoda models, it offers a blend of performance and practicality. The Golf VII saw an increase in size compared to its predecessor while reducing weight by approximately 100 kg depending on engine choice. It was available in various body styles including hatchback and estate (Variant).
History & notable variants
The seventh generation Golf introduced significant advancements, featuring the MQB platform which allowed for improved aerodynamics and reduced weight. Notable performance variants include the GTI Clubsport with enhanced power output and the Golf R AU, known for its high-performance capabilities.
Volkswagen Golf wheel fitment
Everything below is what the fit-check uses for Volkswagen Golf wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Volkswagen Golf (Vii) R AU.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–9J | ET32–ET52 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.0 TSI | VW EA211, 999 cc, CHZK | petrol | 63 kW (85 PS) | FWD, 2017 to 2019 |
| 1.0 TSI | VW EA211, 999 cc, CHZC | petrol | 81 kW (110 PS) | FWD, 2016 to 2018 |
| 1.0 TSI | VW EA211, 999 cc, CHZD | petrol | 85 kW (115 PS) | FWD, 2015 to 2016 |
| 1.0 TSI | VW EA211, 999 cc, DKRF | petrol | 85 kW (115 PS) | FWD, 2018 to 2020 |
| 1.2 TSI | VW EA211, 1,197 cc, CJZB | petrol | 63 kW (85 PS) | FWD, 2012 to 2017 |
| 1.2 TSI | VW EA211, 1,197 cc, CJZA | petrol | 77 kW (105 PS) | FWD, 2012 to 2014 |
| 1.2 TSI | VW EA211, 1,197 cc, CYVB | petrol | 81 kW (110 PS) | FWD, 2014 to 2017 |
| 1.4 TGI | VW EA211, 1,395 cc, CPWA | petrol | 81 kW (110 PS) | FWD, 2013 to 2018 |
| 1.4 TSI | VW EA211, 1,395 cc, CMBA, CPVA | petrol | 90 kW (122 PS) | FWD, 2012 to 2014 |
| 1.4 TSI | VW EA211, 1,395 cc, CZCA | petrol | 92 kW (125 PS) | FWD, 2014 to 2018 |
| 1.4 TSI (ACT) | VW EA211, 1,395 cc, CHPA, (CPTA) | petrol | 103 kW (140 PS) | FWD, 2012 to 2014 |
| 1.4 TSI (ACT) | VW EA211, 1,395 cc, CZDA, (CZEA) | petrol | 110 kW (150 PS) | FWD, 2014 to 2017 |
| 1.5 TGI | VW EA211 evo, 1,498 cc, DHFA | petrol | 96 kW (130 PS) | FWD, 2019 to 2020 |
| 1.5 TSI (ACT) | VW EA211 evo, 1,498 cc, DACA | petrol | 96 kW (130 PS) | FWD, 2017 to 2020 |
| 1.5 TSI (ACT) | VW EA211 evo, 1,498 cc, DADA, DPCA | petrol | 110 kW (150 PS) | FWD, 2017 to 2020 |
| 1.8 TSI | VW EA888, 1,798 cc, CXB | petrol | 126 kW (172 PS) | FWD, 2014 to 2019 |
| 1.8 TSI | VW EA888, 1,798 cc, CJSB | petrol | 132 kW (180 PS) | 4MOTION, 2015 to 2018 |
| GTI | EA888 3. Generation, 1,984 cc, CHHB | petrol | 162 kW (220 PS) | FWD, 2013 to 2017 |
| GTI | EA888 3. Generation, 1,984 cc, CHHA | petrol | 169 kW (230 PS) | FWD, 2017 to 2018 |
| GTI „Performance“ | EA888 3. Generation, 1,984 cc, CHHA | petrol | 169 kW (230 PS) | FWD, 2013 to 2017 |
| GTI „Performance“ | EA888 3. Generation, 1,984 cc, DLBA, DKTB | petrol | 180 kW (245 PS) | FWD, 2017 to 2019 |
| GTI „Clubsport“ | EA888 3. Generation, 1,984 cc, CJXE | petrol | 195 kW (265 PS) | FWD, 2016 to 2017 |
| GTI „Clubsport S“ | EA888 3. Generation, 1,984 cc, CJXG | petrol | 228 kW (310 PS) | FWD, 2016 to 2017 |
| GTI TCR | EA888 3. Generation, 1,984 cc, DNUC | petrol | 213 kW (290 PS) | FWD, 2019 |
| R | EA888 3. Generation, 1,984 cc, CJXC | petrol | 221 kW (300 PS) | 4MOTION, 2013 to 2017 |
| R | EA888 3. Generation, 1,984 cc, DNUE | petrol | 221 kW (300 PS) | 4MOTION, 2018 to 2020 |
| R | EA888 3. Generation, 1,984 cc, CJXG, DJHA | petrol | 228 kW (310 PS) | 4MOTION, 2017 to 2018 |
| R360S | EA888 3. Generation, 1,984 cc, CJXC | petrol | 265 kW (360 PS) | 4MOTION, 2016 to 2017 |
| 1.6 TDI | VW EA288, 1,598 cc, CRKA, CLHB | diesel | 66 kW (90 PS) | FWD, 2013 to 2020 |
| 1.6 TDI | VW EA288, 1,598 cc, CLHA | diesel | 77 kW (105 PS) | FWD or 4MOTION, 2012 to 2014 |
| 1.6 TDI | VW EA288, 1,598 cc, CRKB, CXXB | diesel | 81 kW (110 PS) | FWD or 4MOTION, 2013 to 2017 |
| 1.6 TDI | VW EA288, 1,598 cc, DDYA, DGTE | diesel | 85 kW (115 PS) | FWD, 2017 to 2020 |
| 2.0 TDI | VW EA288, 1,968 cc, CRBC, CRLB, (CRBB ) | diesel | 110 kW (150 PS) | FWD or 4MOTION, 2012 to 2014 |
| 2.0 TDI | VW EA288, 1,968 cc, CRMB, DCYA, DEJA, CRLB | diesel | 110 kW (150 PS) | FWD or 4MOTION, 2014 to 2020 |
| 2.0 TDI (Alltrack) | VW EA288, 1,968 cc, CUNA, DGCA, DJGA | diesel | 135 kW (184 PS) | AWD, 2014 to 2020 |
| GTD | VW EA288, 1,968 cc, CUNA, DGCA, DJGA | diesel | 135 kW (184 PS) | FWD, 2013 to 2019 |
| GTE | VW EA211, 1,395 cc, CUK/CUKB | phev | 150 kW (204 PS) | FWD, 2014 to 2020 |
Source: VW Golf VII, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.0 TSI | 63 kW (85 PS) | 11.9 s | 180 km/h (112 mph) |
| 1.0 TSI | 81 kW (110 PS) | 9.9 s | 196 km/h (122 mph) |
| 1.0 TSI | 85 kW (115 PS) | 9.7 s | 204 km/h (127 mph) |
| 1.0 TSI | 85 kW (115 PS) | 9.8 s | 198 km/h (123 mph) |
| 1.2 TSI | 63 kW (85 PS) | 11.9 s | 179 km/h (111 mph) |
| 1.2 TSI | 77 kW (105 PS) | 10.2 s | 192 km/h (119 mph) |
| 1.2 TSI | 81 kW (110 PS) | 9.2 s | 195 km/h (121 mph) |
| 1.4 TGI | 81 kW (110 PS) | 10.9 s | 194 km/h (121 mph) |
| 1.4 TSI | 90 kW (122 PS) | 9.3 s | 203 km/h (126 mph) |
| 1.4 TSI | 92 kW (125 PS) | 9.1 s | 204 km/h (127 mph) |
| 1.4 TSI (ACT) | 103 kW (140 PS) | 8.4 s | 212 km/h (132 mph) |
| 1.4 TSI (ACT) | 110 kW (150 PS) | 8.2 s | 216 km/h (134 mph) |
| 1.5 TGI | 96 kW (130 PS) | 9.6 s | 206 km/h (128 mph) |
| 1.5 TSI (ACT) | 96 kW (130 PS) | 9.1 s | 210 km/h (130 mph) |
| 1.5 TSI (ACT) | 110 kW (150 PS) | 8.3 s | 216 km/h (134 mph) |
| 1.8 TSI | 126 kW (172 PS) | 7.6 s | 209 km/h (130 mph) |
| 1.8 TSI | 132 kW (180 PS) | 7.8 s | 217 km/h (135 mph) |
| GTI | 162 kW (220 PS) | 6.5 s | 244 to 246 km/h (152 to 153 mph) |
| GTI | 169 kW (230 PS) | 6.4 s | 248 to 250 km/h (154 to 155 mph) |
| GTI „Performance“ | 169 kW (230 PS) | 6.4 s | 248 to 250 km/h (154 to 155 mph) |
| GTI „Performance“ | 180 kW (245 PS) | 6.2 s | 250 km/h (155 mph) |
| GTI „Clubsport“ | 195 kW (265 PS) | 6.3 s | 250 km/h (155 mph) |
| GTI „Clubsport S“ | 228 kW (310 PS) | 5.8 s | 265 km/h (165 mph) |
| GTI TCR | 213 kW (290 PS) | 5.6 s | 250 km/h (155 mph) |
| R | 221 kW (300 PS) | 4.9 to 5.1 s | 250 km/h (155 mph) |
| R | 221 kW (300 PS) | 4.7 to 4.9 s | 250 km/h (155 mph) |
| R | 228 kW (310 PS) | 4.6 to 5.1 s | 250 km/h (155 mph) |
| R360S | 265 kW (360 PS) | 4.7 s | 265 km/h (165 mph) |
| 1.6 TDI | 66 kW (90 PS) | 11.9 s | 185 km/h (115 mph) |
| 1.6 TDI | 77 kW (105 PS) | 10.5 to 11.7 s | 187 to 192 km/h (116 to 119 mph) |
| 1.6 TDI | 81 kW (110 PS) | 10.5 to 11.3 s | 191 to 200 km/h (119 to 124 mph) |
| 1.6 TDI | 85 kW (115 PS) | 10.2 to 10.5 s | 198 km/h (123 mph) |
| 2.0 TDI | 110 kW (150 PS) | 8.6 s | 211 to 216 km/h (131 to 134 mph) |
| 2.0 TDI | 110 kW (150 PS) | 8.6 s | 211 to 216 km/h (131 to 134 mph) |
| 2.0 TDI (Alltrack) | 135 kW (184 PS) | 7.8 s | 230 km/h (143 mph) |
| GTD | 135 kW (184 PS) | 7.5 s | 228 to 230 km/h (142 to 143 mph) |
| GTE | 150 kW (204 PS) | 7.6 s | 130 to 222 km/h (81 to 138 mph) |
Source: VW Golf VII, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 944,531 Volkswagen Golf on UK roads, placing it in the top 1% of car models by volume across our fitment database.
With that many on the road, Volkswagen Golf wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 4,255 to 4,586 mm |
| Width | 1,799 mm |
| Height | 1,442 to 1,515 mm |
| Wheelbase | 2,637 mm |
| Kerb weight | 1,206 to 1,615 kg |
Source: VW Golf VII, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Kombilimousine, Kombi |
| Produced | 1974–present |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Improved aerodynamics, reduced weight, high-performance variants
- Cons: No specific cons mentioned in the reference
- Common issues: No reliability issues specified
