Volkswagen Golf wheel fitment — Vii /-Variant AU, AUV, 1K, 1KM
Volkswagen Golf wheel fitment
Volkswagen Golf wheel fitment for the Volkswagen Golf (Vii) /-Variant AU, AUV, 1K, 1KM (2013–2019): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–9J | ET32–ET52 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 944,531 Volkswagen Golf on UK roads, placing it in the top 1% of car models by volume across our fitment database.
With that many on the road, Volkswagen Golf wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Overview
The Volkswagen Golf (Vii) is a compact car/small family car produced by Volkswagen since its debut at the Paris Motor Show in September 2012. It uses the new MQB platform, shared with other models like the Audi A3, SEAT Leon, and Škoda Octavia. The seventh generation of Golf was slightly larger than its predecessor but managed to be around 100 kg lighter depending on engine choice. This generation marked a significant shift in design philosophy towards aerodynamics and efficiency while maintaining Volkswagen's reputation for reliability and performance.
Dimensions
| Kerb weight | 1,217 to 1,615 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Body styles | Kombilimousine, Kombi |
| Produced | 2013–2019 |
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.0 TSI | VW EA211, 999 cc, CHZK | petrol | 63 kW (85 PS) | FWD, 2017 to 2019 |
| 1.0 TSI | VW EA211, 999 cc, CHZC | petrol | 81 kW (110 PS) | FWD, 2016 to 2018 |
| 1.0 TSI | VW EA211, 999 cc, CHZD | petrol | 85 kW (115 PS) | FWD, 2015 to 2016 |
| 1.0 TSI | VW EA211, 999 cc, DKRF | petrol | 85 kW (115 PS) | FWD, 2018 to 2020 |
| 1.2 TSI | VW EA211, 1,197 cc, CJZB | petrol | 63 kW (85 PS) | FWD, 2012 to 2017 |
| 1.2 TSI | VW EA211, 1,197 cc, CJZA | petrol | 77 kW (105 PS) | FWD, 2012 to 2014 |
| 1.2 TSI | VW EA211, 1,197 cc, CYVB | petrol | 81 kW (110 PS) | FWD, 2014 to 2017 |
| 1.4 TGI | VW EA211, 1,395 cc, CPWA | petrol | 81 kW (110 PS) | FWD, 2013 to 2018 |
| 1.4 TSI | VW EA211, 1,395 cc, CMBA, CPVA | petrol | 90 kW (122 PS) | FWD, 2012 to 2014 |
| 1.4 TSI | VW EA211, 1,395 cc, CZCA | petrol | 92 kW (125 PS) | FWD, 2014 to 2018 |
| 1.4 TSI (ACT) | VW EA211, 1,395 cc, CHPA, (CPTA) | petrol | 103 kW (140 PS) | FWD, 2012 to 2014 |
| 1.4 TSI (ACT) | VW EA211, 1,395 cc, CZDA, (CZEA) | petrol | 110 kW (150 PS) | FWD, 2014 to 2017 |
| 1.5 TGI | VW EA211 evo, 1,498 cc, DHFA | petrol | 96 kW (130 PS) | FWD, 2019 to 2020 |
| 1.5 TSI (ACT) | VW EA211 evo, 1,498 cc, DACA | petrol | 96 kW (130 PS) | FWD, 2017 to 2020 |
| 1.5 TSI (ACT) | VW EA211 evo, 1,498 cc, DADA, DPCA | petrol | 110 kW (150 PS) | FWD, 2017 to 2020 |
| 1.8 TSI | VW EA888, 1,798 cc, CXB | petrol | 126 kW (172 PS) | FWD, 2014 to 2019 |
| 1.8 TSI | VW EA888, 1,798 cc, CJSB | petrol | 132 kW (180 PS) | 4MOTION, 2015 to 2018 |
| GTI | EA888 3. Generation, 1,984 cc, CHHB | petrol | 162 kW (220 PS) | FWD, 2013 to 2017 |
| GTI | EA888 3. Generation, 1,984 cc, CHHA | petrol | 169 kW (230 PS) | FWD, 2017 to 2018 |
| GTI „Performance“ | EA888 3. Generation, 1,984 cc, CHHA | petrol | 169 kW (230 PS) | FWD, 2013 to 2017 |
| GTI „Performance“ | EA888 3. Generation, 1,984 cc, DLBA, DKTB | petrol | 180 kW (245 PS) | FWD, 2017 to 2019 |
| GTI „Clubsport“ | EA888 3. Generation, 1,984 cc, CJXE | petrol | 195 kW (265 PS) | FWD, 2016 to 2017 |
| GTI „Clubsport S“ | EA888 3. Generation, 1,984 cc, CJXG | petrol | 228 kW (310 PS) | FWD, 2016 to 2017 |
| GTI TCR | EA888 3. Generation, 1,984 cc, DNUC | petrol | 213 kW (290 PS) | FWD, 2019 |
| R | EA888 3. Generation, 1,984 cc, CJXC | petrol | 221 kW (300 PS) | 4MOTION, 2013 to 2017 |
| R | EA888 3. Generation, 1,984 cc, DNUE | petrol | 221 kW (300 PS) | 4MOTION, 2018 to 2020 |
| R | EA888 3. Generation, 1,984 cc, CJXG, DJHA | petrol | 228 kW (310 PS) | 4MOTION, 2017 to 2018 |
| R360S | EA888 3. Generation, 1,984 cc, CJXC | petrol | 265 kW (360 PS) | 4MOTION, 2016 to 2017 |
| 1.6 TDI | VW EA288, 1,598 cc, CRKA, CLHB | diesel | 66 kW (90 PS) | FWD, 2013 to 2020 |
| 1.6 TDI | VW EA288, 1,598 cc, CLHA | diesel | 77 kW (105 PS) | FWD or 4MOTION, 2012 to 2014 |
| 1.6 TDI | VW EA288, 1,598 cc, CRKB, CXXB | diesel | 81 kW (110 PS) | FWD or 4MOTION, 2013 to 2017 |
| 1.6 TDI | VW EA288, 1,598 cc, DDYA, DGTE | diesel | 85 kW (115 PS) | FWD, 2017 to 2020 |
| 2.0 TDI | VW EA288, 1,968 cc, CRBC, CRLB, (CRBB ) | diesel | 110 kW (150 PS) | FWD or 4MOTION, 2012 to 2014 |
| 2.0 TDI | VW EA288, 1,968 cc, CRMB, DCYA, DEJA, CRLB | diesel | 110 kW (150 PS) | FWD or 4MOTION, 2014 to 2020 |
| 2.0 TDI (Alltrack) | VW EA288, 1,968 cc, CUNA, DGCA, DJGA | diesel | 135 kW (184 PS) | AWD, 2014 to 2020 |
| GTD | VW EA288, 1,968 cc, CUNA, DGCA, DJGA | diesel | 135 kW (184 PS) | FWD, 2013 to 2019 |
| GTE | VW EA211, 1,395 cc, CUK/CUKB | phev | 150 kW (204 PS) | FWD, 2014 to 2020 |
Source: VW Golf VII, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.0 TSI | 63 kW (85 PS) | 11.9 s | 180 km/h (112 mph) |
| 1.0 TSI | 81 kW (110 PS) | 9.9 s | 196 km/h (122 mph) |
| 1.0 TSI | 85 kW (115 PS) | 9.7 s | 204 km/h (127 mph) |
| 1.0 TSI | 85 kW (115 PS) | 9.8 s | 198 km/h (123 mph) |
| 1.2 TSI | 63 kW (85 PS) | 11.9 s | 179 km/h (111 mph) |
| 1.2 TSI | 77 kW (105 PS) | 10.2 s | 192 km/h (119 mph) |
| 1.2 TSI | 81 kW (110 PS) | 9.2 s | 195 km/h (121 mph) |
| 1.4 TGI | 81 kW (110 PS) | 10.9 s | 194 km/h (121 mph) |
| 1.4 TSI | 90 kW (122 PS) | 9.3 s | 203 km/h (126 mph) |
| 1.4 TSI | 92 kW (125 PS) | 9.1 s | 204 km/h (127 mph) |
| 1.4 TSI (ACT) | 103 kW (140 PS) | 8.4 s | 212 km/h (132 mph) |
| 1.4 TSI (ACT) | 110 kW (150 PS) | 8.2 s | 216 km/h (134 mph) |
| 1.5 TGI | 96 kW (130 PS) | 9.6 s | 206 km/h (128 mph) |
| 1.5 TSI (ACT) | 96 kW (130 PS) | 9.1 s | 210 km/h (130 mph) |
| 1.5 TSI (ACT) | 110 kW (150 PS) | 8.3 s | 216 km/h (134 mph) |
| 1.8 TSI | 126 kW (172 PS) | 7.6 s | 209 km/h (130 mph) |
| 1.8 TSI | 132 kW (180 PS) | 7.8 s | 217 km/h (135 mph) |
| GTI | 162 kW (220 PS) | 6.5 s | 244 to 246 km/h (152 to 153 mph) |
| GTI | 169 kW (230 PS) | 6.4 s | 248 to 250 km/h (154 to 155 mph) |
| GTI „Performance“ | 169 kW (230 PS) | 6.4 s | 248 to 250 km/h (154 to 155 mph) |
| GTI „Performance“ | 180 kW (245 PS) | 6.2 s | 250 km/h (155 mph) |
| GTI „Clubsport“ | 195 kW (265 PS) | 6.3 s | 250 km/h (155 mph) |
| GTI „Clubsport S“ | 228 kW (310 PS) | 5.8 s | 265 km/h (165 mph) |
| GTI TCR | 213 kW (290 PS) | 5.6 s | 250 km/h (155 mph) |
| R | 221 kW (300 PS) | 4.9 to 5.1 s | 250 km/h (155 mph) |
| R | 221 kW (300 PS) | 4.7 to 4.9 s | 250 km/h (155 mph) |
| R | 228 kW (310 PS) | 4.6 to 5.1 s | 250 km/h (155 mph) |
| R360S | 265 kW (360 PS) | 4.7 s | 265 km/h (165 mph) |
| 1.6 TDI | 66 kW (90 PS) | 11.9 s | 185 km/h (115 mph) |
| 1.6 TDI | 77 kW (105 PS) | 10.5 to 11.7 s | 187 to 192 km/h (116 to 119 mph) |
| 1.6 TDI | 81 kW (110 PS) | 10.5 to 11.3 s | 191 to 200 km/h (119 to 124 mph) |
| 1.6 TDI | 85 kW (115 PS) | 10.2 to 10.5 s | 198 km/h (123 mph) |
| 2.0 TDI | 110 kW (150 PS) | 8.6 s | 211 to 216 km/h (131 to 134 mph) |
| 2.0 TDI | 110 kW (150 PS) | 8.6 s | 211 to 216 km/h (131 to 134 mph) |
| 2.0 TDI (Alltrack) | 135 kW (184 PS) | 7.8 s | 230 km/h (143 mph) |
| GTD | 135 kW (184 PS) | 7.5 s | 228 to 230 km/h (142 to 143 mph) |
| GTE | 150 kW (204 PS) | 7.6 s | 130 to 222 km/h (81 to 138 mph) |
Source: VW Golf VII, de.wikipedia.org.
Trim levels
Factory colours
History & notable variants
The Mk7 introduced several notable changes, including the adoption of the MQB platform which allowed for greater flexibility in powertrain options and improved weight distribution. The Golf VII was praised for its advanced technology features and enhanced driving dynamics. Notable variants included the GTI Clubsport with 195 kW (261 hp) and the Golf R with a powerful 220 kW (300 hp) engine, both showcasing Volkswagen's commitment to performance.
Reliability & owner notes
- Pros: Advanced technology features; Improved aerodynamics and efficiency; Enhanced driving dynamics
- Cons: No specific cons mentioned in the reference
