Volkswagen Id.Buzz Pro / Gtx EB side profile — Volkswagen ID.Buzz wheel fitment

Volkswagen ID.Buzz wheel fitment — Pro / Gtx EB

By Torque, AIWheelTech vehicle & fitment specialist · 2022–2022
Volkswagen ID.Buzz wheel fitment in one line: The Volkswagen Id.Buzz Pro / Gtx EB (2022–2022) uses a 5x112 bolt pattern, 57.1 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~8J–9J wheels at ET28–ET45.

Overview

The Volkswagen ID. Buzz is a battery electric minivan produced by German manufacturer Volkswagen, based on the dedicated MEB platform. It is the first production electric minivan from Volkswagen and part of the Volkswagen ID. series. Inspired by the iconic Volkswagen Type 2 (T1) Microbus, it features retro styling with modern technology. The vehicle was unveiled in March 2022, with production starting in June 7, 2022, and European deliveries began in the second half of that year. It is available as a five-seater passenger van and a cargo van (ID. Buzz Cargo). In North America, it launched on June 2, 2023, and became available for sale in June 2024 with a long-wheelbase version.

Volkswagen ID.Buzz wheel fitment

Start with the hub. The Volkswagen Id.Buzz Pro / Gtx EB spec table gives the bolt pattern and bore; the second table is the aftermarket window for Volkswagen ID.Buzz wheel fitment.

Bolt pattern (PCD)5x112
Centre bore57.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8J–9JET28–ET45

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Volkswagen ID.Buzz →Get them fitted (UK)

Dimensions

Kerb weight2,459 to 2,650 kg

Source: EU type-approval data (EEA).

Body styles & production

Produced2022–2022

Trim levels

ID. BuzzID. Buzz Cargo

Factory colours

Pomelo Yellow MetallicCandyweissEnergetic OrangeDeepblackBay Leaf GreenPrata SiriusAzul LapisMedium blueUltra VioletMonosilberBlack EbonyFlame RedSagegreen mattSmokey GreyWolf GreyStratos Blue MetallicFlorida Beach Blue MetallicBlue Charcoal MetallicKirschrotEnergetic Orange Metallic

History & notable variants

The ID. Buzz concept was first shown at the 2017 North American International Auto Show. Positive consumer interest led to its production announcement by CEO Herbert Diess in August 2017, with sales beginning in 2022. The production vehicle debuted on March 9, 2022, and series production started in June 2022 at the Hanover factory, which was retooled for EV assembly. Pre-orders began in May 2022, and the first deliveries were scheduled for Q3 2022.
