Volkswagen Toureg wheel fitment — Touareg Ii 7P, 7p
Volkswagen Toureg wheel fitment at a glance — The Volkswagen Touareg (Ii) 7P, 7p (2010–2017) uses a 5x130 bolt pattern, 71.6 mm centre bore, M14x1.5 bolts torqued to ~140 Nm. It accepts ~7.5J–9J wheels at ET37–ET55.
Volkswagen Toureg wheel fitment
Volkswagen Toureg wheel fitment for the Volkswagen Touareg (Ii) 7P, 7p (2010–2017): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x130 |
| Centre bore | 71.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 7.5J–9J | ET37–ET55 |
As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Body styles & production
| Produced | 2010–2017 |
Factory colours
Reef Blue MetallicOryxweiss PerleffektDeep Black PearlAcapulcoblau MetallicFrescogruen MetallicBlack, SchwarzReflex Silver MetallicToffee Brown MetallicSalsarot, Salsa RedBlue Silver MetallicBlue Lagoon Metallic, Ravennablau MetallicDeep Blue PearlAlaska Gray MetallicArctic Blue Silver MetallicBiscay Blue PearlRacinggruen PearlGalapagos MetallicDark Flint Gray MetallicCanyon Gray MetallicSalt Lake Grau Metallic
