Volkswagen (T6) 7HMA side profile — Volkswagen Transporter wheel fitment

Volkswagen Transporter wheel fitment — T6 7HMA

By Torque, AIWheelTech vehicle & fitment specialist · 2015–2019
Volkswagen Transporter wheel fitment at a glance — The Volkswagen (T6) 7HMA (2015–2019) uses a 5x120 bolt pattern, 65.1 mm centre bore, M14x1.5 bolts torqued to ~140 Nm. It accepts ~6.5J–9.5J wheels at ET35–ET56.

Overview

The Volkswagen Transporter T6 is the sixth generation of the Volkswagen Transporter vans, succeeding the T5 model. It was manufactured by Volkswagen Commercial Vehicles and assembled in Hannover, Germany; Poznań, Poland; and Kaluga, Russia. The T6 platform retained elements from its predecessor but introduced significant updates such as a new dashboard layout (standard and 'comfort' versions), revised front end styling, LED lighting options, and enhanced driver assistance features. It was available in various body styles including van, minibus, crew cab, chassis cab, and campervan configurations.

Volkswagen Transporter wheel fitment

Volkswagen Transporter wheel fitment for the Volkswagen (T6) 7HMA (2015–2019): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x120
Centre bore65.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque140 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6.5J–9.5JET35–ET56

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Volkswagen Transporter →Get them fitted (UK)

UK popularity & demand

~16,862 Volkswagen Transporter licensed on UK roads — top 11% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 16,862 Volkswagen Transporter on UK roads, placing it in the top 11% of car models by volume across our fitment database.

That makes Volkswagen Transporter wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
TDI4002.0L TDI turbo dieseldiesel175 hp4Motion
2.0BiTDI 204PS (Euro6B)2.0L BiTDi twin-turbo dieseldiesel152 hp4Motion
2.0BiTDI 199PS (Euro6D)2.0L BiTDi twin-turbo dieseldiesel148 hp4Motion
TDI3402.0L TDI turbo dieseldiesel136 hpFWD
2.0TDI 150PS (Euro6D)2.0L TDI dieseldiesel111 hp4Motion
2.0TDI 110PS (Euro6D)2.0L TDI dieseldiesel82 hpFWD
ABT e-TransporterElectric motorelectric81 hpFWD
2.0TDI 102PS (Euro6D)2.0L TDI dieseldiesel76 hpFWD
2.0TDI 90PS (Euro6D)2.0L TDI dieseldiesel67 hpFWD

Performance

VariantPower0–62 mphTop speed
ABT e-Transporter81 hp7.9 s84 mph

Dimensions

Length4904 mm
Width2297 mm
Height1990 mm
Wheelbase3000 mm

Body styles & production

Body stylesVan (cargo/passenger), Pick-up, Minibus, Crew cab, Chassis cab, Campervan
Produced2015–2019

Trim levels

StartlineTrendlineHighline

Factory colours

HONIGGELBCORAL REDTEAL BLUE/AQUA WAVEBLACK RUBINMALBEC REDFRESH FUCHSIACARAMEL BROWNARAGONIT BRAUNVIOLETTO PURPLEGREYKURKUMAGELBVELVET BROWNPFAUENGRUENOBSIDIAN GREYTOURMALINE BLUENIGHTSHADE BLUEVIOLETOKIWI GREENPYRIT SILBERPEBBLESTONE GREY

History & notable variants

The T6 underwent a mid-cycle refresh to become the T6.1 in 2019, featuring electric power steering for improved handling and more advanced driver assistance systems. The ABT e-Transporter was introduced as an electric variant of the T6.1 in 2020. Production ended in 2024 due to EU regulations requiring enhanced cybersecurity measures.

Reliability & owner notes
