Volkswagen (T6) 7HC side profile — Volkswagen Transporter wheel fitment

Volkswagen Transporter wheel fitment — T6 7HC

By Torque, AIWheelTech vehicle & fitment specialist · 2015–2022
Volkswagen Transporter wheel fitment at a glance — The Volkswagen (T6) 7HC (2015–2022) uses a 5x120 bolt pattern, 65.1 mm centre bore, M14x1.5 bolts torqued to ~140 Nm. It accepts ~6.5J–9.5J wheels at ET35–ET56.

Overview

The Volkswagen Transporter T6 is the sixth generation of the Volkswagen Transporter vans, succeeding the T5. It was manufactured by Volkswagen Commercial Vehicles and assembled in Hannover, Germany; Poznań, Poland; and Kaluga, Russia. The T6 retained the 7H/7J platform from its predecessor but featured numerous updates including a new dashboard layout, LED lighting options, and advanced driver assistance systems. Available in various body styles such as van, pick-up truck, minibus, crew cab, chassis cab, and campervan, it was positioned between Volkswagen's larger Crafter and smaller Caddy models.

Volkswagen Transporter wheel fitment

Volkswagen Transporter wheel fitment for the Volkswagen (T6) 7HC (2015–2022): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x120
Centre bore65.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque140 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6.5J–9.5JET35–ET56

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Volkswagen Transporter →Get them fitted (UK)

UK popularity & demand

~16,862 Volkswagen Transporter licensed on UK roads — top 11% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 16,862 Volkswagen Transporter on UK roads, placing it in the top 11% of car models by volume across our fitment database.

That makes Volkswagen Transporter wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
TDI4002.0L TDI turbo dieseldiesel175 hp4Motion
2.0BiTDI 204PS (Euro6B)2.0L BiTDi twin-turbo dieseldiesel152 hp4Motion
2.0BiTDI 199PS (Euro6D)2.0L BiTDi twin-turbo dieseldiesel148 hp4Motion
TDI3402.0L TDI turbo dieseldiesel136 hpFWD
2.0TDI 150PS (Euro6D)2.0L TDI dieseldiesel111 hp4Motion
2.0TDI 110PS (Euro6D)2.0L TDI dieseldiesel82 hpFWD
ABT e-TransporterElectric motorelectric81 hpFWD
2.0TDI 102PS (Euro6D)2.0L TDI dieseldiesel76 hpFWD
2.0TDI 90PS (Euro6D)2.0L TDI dieseldiesel67 hpFWD

Performance

VariantPower0–62 mphTop speed
ABT e-Transporter81 hp7.9 s85 mph

Dimensions

Length4904,5304 mm
Width2297 mm
Height1990,2176,2477 mm
Wheelbase3000,3400 mm

Body styles & production

Body stylesVan, Pick-up truck, Minibus, Crew cab, Chassis cab, Campervan
Produced2015–2022

Trim levels

StartlineTrendlineHighline

Factory colours

HONIGGELBCORAL REDTEAL BLUE/AQUA WAVEBLACK RUBINMALBEC REDFRESH FUCHSIACARAMEL BROWNARAGONIT BRAUNVIOLETTO PURPLEGREYKURKUMAGELBVELVET BROWNPFAUENGRUENOBSIDIAN GREYTOURMALINE BLUENIGHTSHADE BLUEVIOLETOKIWI GREENPYRIT SILBERPEBBLESTONE GREY

History & notable variants

The T6 underwent a mid-cycle refresh to become the T6.1 in 2019, featuring electric power steering for enhanced driver assist functions and minor styling updates. In 2020, ABT e-Line collaborated with VW to introduce the ABT e-Transporter 6.1 as an electric variant of the T6.1. The T6 series was discontinued in favor of the MQB-based Multivan T7 due to EU regulations requiring cybersecurity compliance for new vehicles from 2024.

Reliability & owner notes
